ADAR1000-EVALZ
EVALUATION BOARD SOFTWARE INSTALLATION
To install the ADAR1000-EVALZ evaluation board software,
take the following steps:
1.
The evaluation software archive is available for download
on the
ADAR1000 evaluation kit
2.
Save the adar1000_eb_sw_2p1p0.zip to the Downloads
folder or any other convenient location (see Figure 4).
Navigate to that location using File Manager, and double-
click the file name to open it.
Figure 4. Saving Downloaded Control Software Archive
User Guide
product page.
3.
File Manager then shows the content of the archive, as
shown in Figure 5.
4.
Double-click on the filename EV-ADAR1000_2p1p0.exe
to start installation. Click Yes when asked to allow the
program to make modifications to the PC. Administrator
privileges may be required to complete the step.
5.
After the application is installed, ADAR1000 is available
from the Start menu under the Analog Devices folder.
Rev. 0 | Page 7 of 18
Figure 5. Unpacking Software Archive
UG-1283
