(1)-2 Test name
Displays the current test and program
There are two types of programs to select from:
• Custom program
• Semi-Auto program :By clicking the desired chart on the chart page, it will be
For the custom program, the charts can be selected and customized by press-
ing [Settings]
Refer to "6.3.2 CUSTOMIZE THE TEST PROCEDURE" on P.146 for cus-
tomizing the program course.
For the "Semi-Auto" course, each chart can be customized by [Settings]. To
customize the "Semi-Auto" course, change the test parameters registered in the
test chart icons.
Refer to "6.3.1 CUSTOMIZING THE CHART PAGE" on P.141 for details.
(1)-3 Time and lapse of test
Displays the date, time and lapse time since the test started. Only one of them
(date or lapse time since the test started) can be displayed by [Settings].
Refer to "8.2.7 Screen settings" on P.192.
(2) Main data
Displays the data and visual acuity value set in the measuring head.
(2)-1
:Click the [Course list] button to select. The measure-
ments can be performed in the sequence that was pro-
grammed .
displayed. Measurements can be performed using each
chart individually.
(2)-3
(2)-4
(2)-2
