S U R E S H A D E T E C H N I C A L D O C U M E N T A T I O N
RTX Pull-Out Shade
General Installation Instructions
The following instructions detail how to properly install
SureShade RTX on a tower or hardtop for DIY or
aftermarket installations.
SureShade RTX Pull-Out Shade can also be installed
aftermarket on a hardtop, arch, tower or T-Top.
Installation instructions will vary per application.
Illustrations provided
by Tim Barker - Boating Magazine
Page 1 of 4
TOOLS & SUPPLIES:
SureShade RTX
•
Tape measure
•
Drill motor and 3/8-inch bit
•
Adjustable wrench
•
Allen wrenches (1/8 and
•
3/16 inches)
Phillips screwdriver
•
Marine sealant
•
Approximate Time: 3 hours
SURESHADE
PO Box 51294
Philadelphia, PA 19115
Tel: 1-877-333-8323
International: 215-673-2307
www.sureshade.com
RTXINSTALL-HARDTOP-0518
