SureShade M3 Installation Instructions Manual

Automated mega shade

S U R E S H A D E T E C H N I C A L D O C U M E N T A T I O N

M3 Automated Mega Shade

Installation Instructions

The SureShade® M3 automated mega shade system is an electric

power-driven retractable shade featuring a self-supported

stainless steel framework. The M3 features two crossbars enabling

it to extend up to 10 feet.

This installation guide includes instructions for properly installing

the framework and electrical components for our M3 automated

shade systems.

Page 1 of 5

SURESHADE

PO Box 51294

Philadelphia, PA 19115

Tel: 1-877-333-8323

International: 215-673-2307

www.sureshade.com

M3INSTALL-0518

Table of Contents

Do you have a question about the M3 and is the answer not in the manual?

Page 1 S U R E S H A D E T E C H N I C A L D O C U M E N T A T I O N M3 Automated Mega Shade Installation Instructions The SureShade® M3 automated mega shade system is an electric power-driven retractable shade featuring a self-supported stainless steel framework. The M3 features two crossbars enabling it to extend up to 10 feet.
Page 2 The SureShade as shown in Fig 1 was set to a shade width of XX” center of port actuator to center of starboard actuator as modeled in the supplied 3D engineering file. Fig 1 112 inches For proper operation, it is vital that within the hardtop cavity the actuators are installed at the specified XX”...
Page 3 After drilling the mounting holes, thru-bolting the mounting clamps and securing the actuators in place, insert the outer crossbar into both ends of the actuators to ensure the actuators are mounted to the specified width (Fig 3). The crossbar should slide into the actuator tubes easily when mounted to the proper width.
Page 4 The electrical housing is pre-wired and tested before shipping. This unit is a 12V DC system. The electrical housing controls the retracted and extended positions as well as the synchronization of the actuators’ movement. The synchronization is accomplished by sensors positioned inside the actuator that communicate with the electrical housing.
