SureShade
Power Bimini
Sport Arm Kit
Installation and Owner's Manual
(For Aftermarket Applications)
SureShade
Power Bimini
Sport Arm Kit
Installation and
Owner's Manual
(For Aftermarket Applications)
Power Bimini Front Support Kits
Power Bimini Front Support Kits
2
Part No.
Part No.
Description
Description
2
36" Bimini Front Support Kit - Clear (Silver)
2020134627
3
Anodized
4
2020134628
36" Bimini Front Support Kit - Black Anodized
4
32" Bimini Front Support Kit - Clear (Silver)
2020134625
5
Anodized
6
2020134626
32" Bimini Front Support Kit - Black Anodized
6
10
11
11
11
12
12
12
1
®
®
CCD-0003954
Rev: 01.05.21
