Summary of Contents for Motorline professional BRAVO500

  • Page 1 BRAVO500 USER'S AND INSTALLER'S MANUAL v4.0 REV. 04/2018...
  • Page 2: Table Of Contents

    00. CONTENT 01. SAFETY INSTRUCTIONS INDEX STANDARDS TO FOLLOW 01. SAFETY INSTRUCTIONS This product is certified in accordance with European STANDARDS TO FOLLOW Community (EC) safety standards. 02. PACKAGE INSIDE PACKAGE This product complies with Directive 2011/65/EU of the European Parliament and of the Council, of 8 June 2011, on 03.
  • Page 3: Safety Instructions

    01. SAFETY INSTRUCTIONS 01. SAFETY INSTRUCTIONS STANDARDS TO FOLLOW STANDARDS TO FOLLOW • It is important for your safety that these instructions are followed. automated is in good mechanical condition, correctly balanced and opens • Keep these instructions in a safe place for future reference. and closes properly.
  • Page 4: Package

    Inside the package you will find the following components: During installation you will need to open the motor cover, to access 01• 01 motor Bravo500 07• 02 fixation plate of the limit switches various components on the inside. For 02• 02 release keys 08•...
  • Page 5: Unlock Operator 5A

    TECHNICAL SPECIFICATIONS To open manually the gate in case of electric power failure or in case of damage, follow The specifications of the automatism BRAVO 500 are as follows: the below steps: BRAVO500 BRAVO500/110 • Power Supply AC 230V 50Hz AC 110V 60Hz •...
  • Page 6: Installation

    04. INSTALLATION 04. INSTALLATION INSTALLATION SITE PREPARATION SITE INSTALLATION – CREATE FOUNDATION To ensure full operation of the automatism, pay attention the following recommendations: • Read the entire manual at least once giving special attention to all notices marked with •...
  • Page 7: Site Installation - Existing Foundation 7A

    04. INSTALLATION 04. INSTALLATION SITE INSTALLATION – EXISTING FOUNDATION APPLICATION OF MOTOR In case there is already a foundation at the installation site, proceed as below: 60mm 60mm 01 • Remove the side covers of the motor 02 • Place the motor in the fixing plate. 01 •...
  • Page 8: Installation Of Steel Gear Rack 8A

    04. INSTALLATION 04. INSTALLATION INSTALLATION OF STEEL GEAR RACK INSTALLATION OF STEEL GEAR RACK Place the gate in the open position and unlock the motor! (p.03A). ) DETAIL 29 05 • Close the gate a bit, so that the rack is not being supported on the pinion anymore 01 •...
  • Page 9: Installation Of Nylon Gear Rack 9A

    04. INSTALLATION 04. INSTALLATION INSTALLATION OF NYLON GEAR RACK INSTALLATION OF NYLON GEAR RACK Place the gate in the open position and unlock the motor! (p.03A) 04 • Close the gate a bit, so that the rack is not being supported on the pinion anymore and apply another piece of rack (A), fitting it into the rack already installed (B), as you can see in detail of image 41.
  • Page 10: Installation Of Plates The Limit Switches 10A

    04. INSTALLATION 04. INSTALLATION INSTALLATION OF PLATES THE LIMIT SWITCHES CLUTCH ADJUSTMENT To start the disassembly of the control board, disconnect the power and have Place the gate in the open position and unlock the motor! (p.03A) maximum care when handling it. 01 •...
  • Page 11: Map Of Installation

    04. INSTALLATION MAP OF INSTALLATION • FLASH LAMP • ANTENNA • CONTROL • BRAVO500 • PHOTOCELL • PHOTOCELL • KEY SELECTOR BOARD LEGEND: • Cables of connection It is important to use stoppers on the opening and closing of the gate. If this is not It is important to use junction boxes for connections between motors, components and control board.
  • Page 12: Troubleshooting

    05. TROUBLESHOOTING 05. TROUBLESHOOTING FINAL CONSUMERS INSTRUCTIONS FINAL CONSUMERS INSTRUCTIONS SPECIALIZED TECHNICIANS INSTRUCTIONS SPECIALIZED TECHNICIANS INSTRUCTIONS Problem Procedure Behavior Procedure II Discovering the origin of the problem • Motor • Make sure you • Still not working • Consult a qualified 1 •...
  • Page 13: Components Test

    06. COMPONENTS TEST 07. MAINTENANCE SCHEMES FOR CAPACITORS MAINTENANCE To detect if the malfunction is on the control board or on the motor is, sometimes, • Check all screws of the automation necessary to perform tests with connection directly to a 110V/230V power supply. such as the fixing plate to the ground, For this, it is necessary to interpose a capacitor on the connection in order to the the plates of the limit switches, motor...
