Summary of Contents for Motorline professional ROLLING Series
- Page 1 ROLLING | ROLLING SP USER'S AND INSTALLER'S MANUAL v2.1 REV. 11/2014...
- Page 2 00. CONTENT 01. SAFETY INSTRUCTIONS INDEX STANDARDS TO FOLLOW 01. SAFETY INSTRUCTIONS ATTENTION: STANDARDS TO FOLLOW • To ensure the safety of people, it is important that you read all the following 02. THE AUTOMATISM instructions. Incorrect installation or incorrect use of the product can cause physical injury and material damage.
-
Page 3: Installation Instructions
01. SAFETY INSTRUCTIONS 02. THE AUTOMATISM STANDARDS TO FOLLOW INSTALLATION INSTRUCTIONS • Do not allow children or adults to stay near the product while it is operating. "L/2" • Transit is permitted only when the automated system is fully openned. •... - Page 4 02. THE AUTOMATISM 02. THE AUTOMATISM INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS 10 • Tighten the M10 screw with nut (B) in order to block the gearmotor on the shaft. 11 • Install the plastic band with rolls (F) in its appropriate place. 12 •...
- Page 5 02. THE AUTOMATISM 02. THE AUTOMATISM INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS 20 • Rotate the plastic washer (Q1) by hand until you hear the click of the microswitch 1 (down regulation completed). 21 • Rotate the other plastic washer (Q2) towards the microswitch 2 (up). Give tension to the motor through an electric command and verify if the shutter, climbing, stops in desired point.
- Page 6 02. THE AUTOMATISM 02. THE AUTOMATISM INSTALLATION OF THE ELECTROBRAKE GEAR MOTOR WITH SAFETY DEVICE 02 • After assembled the two elements of Capacitor the gearmotor (G), check that the pawl (Z) is in the highest position perpendicular 90º Black to the rolling shutter axis (figure 12).
