- Page 1 ROLLING SP USER'S AND INSTALLER'S MANUAL v7.2 REV. 02/2020...
- Page 2 00. CONTENT 01. SAFETY INSTRUCTIONS INDEX STANDARDS TO FOLLOW ATTENTION: 01. SAFETY INSTRUCTIONS STANDARDS TO FOLLOW This product is certified in accordance with European Community 02. THE AUTOMATISM (EC) safety standards. TECHNICAL SPECIFICATIONS INSTALLATION INSTRUCTIONS This product complies with Directive 2011/65/EU of the European INSTALLATION OF THE ELECTROBRAKE Parliament and of the Council, of 8 June 2011, on the restriction GEAR MOTOR WITH SAFETY DEVICE...
- Page 3 01. SAFETY INSTRUCTIONS 01. SAFETY INSTRUCTIONS STANDARDS TO FOLLOW STANDARDS TO FOLLOW • It is important for your safety that these instructions are followed. • Before installing, the installer must verify that the temperature range • Keep these instructions in a safe place for future reference. indicated on the automatism is appropriate to the location of the installation.
- Page 4 02. THE AUTOMATISM 02. THE AUTOMATISM TECHNICAL SPECIFICATIONS INSTALLATION INSTRUCTIONS 04 • Remove the two semi-crown (D) ROLLING ROLLING ROLLING ROLLING unscrewing the two M8 screws (E) as 160SP 360SP 160SP 360SP shown in figure 3. Power supply Torque 230V 50/60Hz 230V 50/60Hz 150Nm 420Nm...
- Page 5 02. THE AUTOMATISM 02. THE AUTOMATISM INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS 17 • Connect the terminal block (M) of the ROLLING 160SP power wire to the limit switch respecting Capacitor the right direction (figure 6). Fasten the Brown terminal block through the four screws. Black Common Switch...
- Page 6 02. THE AUTOMATISM 02. THE AUTOMATISM INSTALLATION INSTRUCTIONS GEAR MOTOR WITH SAFETY DEVICE 20 • Rotate the plastic washer (Q1) by hand until you hear the click of the microswitch Gear motor with safety device carried out to the stop the free fall of roller shutters and at 1 (down regulation completed).
- Page 7 02. THE AUTOMATISM MOTOR UNLOCKING To unlock the motor simply unscrew the unlocking piece at the end of the steel cable by turning it to the left. To lock the engine again, tighten the same piece.
