- Page 1 ROLLING600-800-1000-1500 ROLLING600-800-1000-1500 USER/INSTALLER MANUAL V1.0 REV.03/2024...
-
Page 2: Table Of Contents
00. CONTENT 01. SAFETY INSTRUCTIONS íNDICE This product is certified in accordance with European Community 01. SAFETY INSTRUCTIONS (EC) safety standards. This product complies with Directive 2011/65/EU of the European 02. INFORMATION Parliament and of the Council, of 8 June 2011, on the restriction SECURITY INFORMATION of the use of certain hazardous substances in electrical and TECHNICAL CHARACTERISTICS... -
Page 3: Safety Instructions
01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. • If the power cable is damaged, it must be replaced by the Read all instructions carefully before beginning the installation/ manufacturer, after-sales service or similarly qualified personnel usage procedures and keep this manual in a safe place that it can... - Page 4 01. SAFETY INSTRUCTIONS the power supply cable. Please note that all the cables must enter conditions have been met. the control board from the bottom. • In the event of tripping of circuits breakers of fuse failure, locate • If the automatism is to be installed at a height of more than 2,5m the malfunction and solve it before resetting the circuit breaker or from the ground or other level of access, the minimum safety and replacing the fuse.
-
Page 5: Information
Height Bearing Consumption Input weight speed • L2 Motor Limit switch Screw • L3 External switch: 220Vac ROLLING600SP 410 Nm 600 kg 6.5 rpm 127 mm 2.3A 50/60 Hz • Ground (Yellow/Green) • Brown 220Vac ROLLING800SP 640 Nm 800 kg 3.7 rpm... -
Page 6: Installation And Adjustments
Dimensions for installation (see table). Bearing Shaft Roll Big gear Bracket Model Distance to centers Length Width ROLLING600SP 304 mm 515 mm 300 mm ROLLING800SP Join Circular Plates II to the Roll 345.5 mm 580 mm 320 mm ROLLING1000SP 339 mm... -
Page 7: Installation Of The Gear 6A
04. INSTALLATION AND ADJUSTMENTS 04. INSTALLATION AND ADJUSTMENTS INSTALLATION OF THE GEAR CHAIN Fix the door motor to the gear. Make sure the nuts are tight and the chain is vertical position. The Motor is supplied with a chain for manual lifting of the grille. In case of using the chain, make slow movements to move the grille. -
Page 8: Connection Scheme
05. CONNECTION SCHEME CONNECTION TO SWITCH OR CONTROL BOARD (600-800-1000) SWITCH MC4 EVO (OPTIONAL) MC75 (OPTIONAL) • Included as standard • Control board to work • Control board to work with remote control, only with remote control pushbutton and allows placement of Photocells/Security Systems TIME.P PHOTO... -
Page 9: Connection To Switch Or Control Board (1500)
05. CONNECTION SCHEME CONNECTION TO SWITCH OR CONTROL BOARD (1500) SWITCH MC4 EVO (OPTIONAL) MC75 (OPTIONAL) L1 L2 L3 L1 L2 L3 L1 L2 L3 • Included as standard • Control board to work • Control board to work with remote only with remote control control, pushbutton and allows 400Vac... -
Page 10: Maintenance
06. MAINTENANCE Check the door once a month. The door must be working without any defect. Regularly check the limit switches. For assistance, contact a qualified technician. Our company reserves the right to change the design and specifications without prior notice. TROUBLESHOOTING Behavior Procedure...
