Sterilizable Battery - Zimmer Universal Power System Instruction Manual

DESCRIPTION AND TECHNICAL DATA
CAUTIONS:
ATK housing REF 89-8510-440-10
Remove ATK housing from handpiece after use.
•
Remove battery from housing before sterilizing.
•
• Use only with Zimmer® UNIVERSAL battery (REF 89-8510-440-20).
Do not wash and sterilize with lid closed.
•
• Seal between lid and housing must be present and pressed to guarantee seal.

STERILIZABLE BATTERY

REF 89-8510-440-50
• Rechargeable lithium battery
Sterilizable using FLASH autoclave cycle
•
Technical data
Rated Voltage
Dimensions
Weight
Environmental conditions during operation
Ambient temperature
Relative humidity
Storage and transportation condition
WARNING: Fire and burn hazard. Do not heat above 80°C (176°F) during storage and transportation or incinerate. Exposure
to elevated temperature may reduce battery capacity and performance. When using heat for sterilization strictly follow the
instructions given in the Cleaning, Decontamination and Sterilization section.
CAUTIONS:
Remove sterilizable battery from handpiece after use.
•
Use only FLASH autoclave cycle (See Sterilization section). Do not exceed 4 minutes at 132°C (270°F) or 3 minutes at 134°C
•
(273°F).
The Zimmer® UNIVERSAL Sterilizable Battery is the only component of the Zimmer® UNIVERSAL Power System that can be
•
sterilized using STERRAD® Technology. For details refer to the STERRAD® STERILITY GUIDE.
• Charge only with Zimmer® UNIVERSAL compact battery charger (REF 89-8510-421-00).
Remove from charger when recharged (green indicator light).
•
Allow sufficient time for cooling the sterilizable battery after charging in order to introduce it at a normal operating room
•
temperature in the autoclave.
• Do not immerse or place in automated washer.
16.5V DC, 20A
88 mm x 66 mm x 62 mm
310 grams
10°C to 38°C (50°F to 100°F)
30% to 60%
7
