OPERATING PROCEDURE
RED: Battery is charging
• Indicator
Light
GREEN: Battery is charged and ready
for use
OFF:
Contact your Zimmer local
representative
0
• Push power switch button to
CAUTIONS:
Remove batteries from charger when recharged.
•
Remove batteries before switching off charger.
•
UNIVERSAL battery for Aseptic Transfer Kit (REF 89-8510-440-20)
Contacts
UNIVERSAL sterilizable battery (REF 89-8510-440-50)
Contacts

TO TRANSFER BATTERY INTO STERILE ATK HOUSING

CAUTIONS:
Battery is not sterile; STERILE PERSON must not touch battery during transfer.
•
Housing is sterile; NON-STERILE PERSON must not touch housing during transfer.
•
• Seal between the lid and housing must be present and pressed to guarantee seal.
• STERILE PERSON (A): Position locking system to
Locked
to power off charger.
and open lid of housing.
Unlocked
11
Indicator Light
