To Start The Motor Forward And Reverse; To Charge The Batteries - Zimmer Universal Power System Instruction Manual

OPERATING PROCEDURE

TO START THE MOTOR FORWARD AND REVERSE

UNIVERSAL Double trigger handpiece (REF 89-8507-400-00)
Forward – Lower Trigger
: Pressing higher trigger alone will not result in any operation of the handpiece.
NOTE
UNIVERSAL Single trigger handpiece (REF 89-8507-400-10)
P
: On (Forward)
Position switch to left

TO CHARGE THE BATTERIES

• Connect the Zimmer® UNIVERSAL compact battery
charger to the mains using cord provided.
I
• Push power switch button to
• Four indicator lights on top of charger will be green
when no batteries are connected.
• Connect up to four batteries as illustrated below.
Reverse – Both triggers simultaneously
Q
: On (Reverse)
Position switch to right
to power on charger.
10
Choose the direction of rotation and then
press the trigger
Power Switch button
Mains connection
