Electric Power Supply - Zimmer Universal Power System Instruction Manual

DESCRIPTION AND TECHNICAL DATA
Technical data
Power
Weight
Dimensions
Speed adjustment
Cannulation channel diameter
Power source
Power supply
Operation mode
Run time with battery
Type of protection against electric shock
Degree of protection against electric shock
Degree of protection against water ingress
Environmental conditions during operation
Ambient temperature
Relative humidity
Altitude
NOTE: There are no special requirements for transport or storage. Transport or store in an environment that limits exposure
to dust, moisture and temperature extremes.
CAUTIONS:
• Use only with Zimmer® UNIVERSAL attachments
• Do not immerse handpiece.

ELECTRIC POWER SUPPLY

REF 89-8510-420-00
89-8510-420-10
89-8510-420-20
• Electric power supply
Compatible with Zimmer® UNIVERSAL Battery / Electric
•
handpieces
Technical data
Input
Output
Dimensions
Weight
Type of protection against electric shock
Degree of protection against electric shock
Degree of protection against water ingress
250 Watts typical
780 grams (without battery)
120 mm x 150 mm x 45 mm
0 to 12'000 rpm approximately
5 mm
Mains or Battery
Battery: 16.5V DC, 20A
Mains: 15V DC, 300W
Intermittent: 1 min on / 5 min off; 5 times with a 2 hour rest
Up to 15 min
Battery: Internally powered equipment
Mains: Class I
Type BF applied part
IPXO (ordinary)
10°C to 38°C (50°F to 100°F)
30% to 60%
≤2,000 m – Not intended for high altitude environments
100-240V~, 50-60Hz, 4.6-1.6A
15V DC, 300W
321 mm x 206 mm x 67 mm
2.76 kg approximately (without cord)
Class I
Type BF applied part
IPXO (ordinary)
4
