TempSen Alpha Quick Manual

Quick Guide
QG_141222 REV. A
1> Configuration > a. Online Configuration
Connect Alpha data logger to PC via USB connection, open
online configuration portal www.alphalogger.com
browser, then select the device model you are going to
configure, input configuration parameters, and download
configuration profile (.cfg) and save it to the logger created
removable storage device "TempSenDisk" .
The configuration file could be used for batch configuration
by appling it to other devices of same model.
Configuration profile could only be applied to product
of same model. Configuration profile created contains
Local Time Zone information, so please download new
configuration profile when you are in different time
zone to avoid time error.
a.
Online
Configuration
Download
Configuration
Profile
Save to
TempSenDisk
Configuration Success
(USB connection remains)
1 > Configuration > b. Configuration via TempCentre
Connect logger to PC, open TempCentre software, move to
Configure Device, input configuration parameters, and click
Apply to complete configuration.
Please DO NOT remove logger from PC before you are
prompted of configuration success.
©2015. All rights reserved, TempSen Electronics Company
in internet
b.
Configuration via
TempCentre
Free Download on
www.tempsen.com
Standby for Startup
To learn more operation information about Alpha, please download User Manual via
2> Start and Stop recording
Press and hold the Start/Stop button for 3 seconds to start
recording, appearing on LCD indicates start success.
Press and hold Start/Stop button unil
on home screen to stop recording.
3> Downloading Data
Connect Alpha data logger to USB port, and copy PDF report
from TempSenDisk to your computer.
You could also download device using TempCentre software.
4> LCD Messages
▼ Home Screen
1 2
3
4
Click View/Mark button to step through following recording
summaries.
▼ Logging Statistics
1
▼ Statistics for each alarm zone
Examples below represent statistics for respective alarm zone.
3
2
4
1
3
2
4
1
3
2
4
1
5
T: +86 21 6768 5210 F: +86 21 6768 5232 E: info@tempsen.com W: www.tempsen.com
TempSen Alpha Data Logger
®
www.tempsen.com/alpha/manual
(Stop) appears
1 Overall Status
Alarm
2 Overall Limit violation indication
3 Current reading
4 Remaining battery life in Days
1 Max, Min, Avg Value
1 Alarm Zone: High
2 Status: OK
3 Limit violation: No
4 Duration time: 0 minute
1 Alarm Zone: A2 (Multi-Alarm)
2 Status: Alarm
3 Limit violation: Yes
4 Duration time: 23.6 hours
1 Alarm Zone: Low
2 Status: Alarm
3 Limit violation: Yes
4 Duration time: 8.5 days
5 Channel: Humidity
OK
