TempSen Tempod 90S Quick Manual

Quick Guide
Tempod 90S
®
Single Use Dry Ice Temperature Data Logger
T: +86 21 6768 5210
F: +86 21 6768 5232
E: info@tempsen.com
W: www.tempsen.com
1> Configuration
▼ Configure Device Online
®
Connect Tempod data logger to PC via USB connection, open online configuration portal
ou-tempod.tempsen.com in internet browser, then select the device you are going to configure,
input configuration parameters, download configuration profile (.cfg) and save it to the logger created
Removable Storage Device "TempSenDisk" .
Configuration profile created contains Local Time Zone information, so please download
new configuration profile when you are in different time zone to avoid time error.
▼ Configure Device via TempSen Express
Connect logger to PC, open TempSen Express software, select configuration profile you need and click
"Configure Device".
Please DO NOT remove logger from PC before you are prompted of configuration success.
Please download TempSen Express software from https://www.tempsen.com/downloads
▼ LCD After Configuration
← Standby
Ready for Manual Activiation (Press Start button) after configuration.
Logger enters into sleep mode in 10 sec after configuration, please
press to activate LCD, and logger will enter sleep mode again
if there is no further button actions, until logger is started for recording.
← Auto
Wait for recording begins at preset time automatically after
configuration.
2> Start Recording
Press and hold button for 3 seconds to activate device and start recording.
Meanwhile (Hold) appears on LCD to remind you to keep current button action.
← Start Delay (12.5 days)
LCD changes to time countdown if device was set to a start delay after
successful activation.
appears on downleft corner of LCD indicating recording begins.
↑ Configuration
success
