UMTS/HSPA Module Series
UC20 PPP Application Note
5

PPP Dial-up in Windows

5.1. Preparation

It is necessary to finish the following steps before establishing a PPP connection.
Connect the module to PC and enter the PIN code if the SIM card PIN is locked.
Make sure the SIM card can successfully register to the GPRS network.

5.2. Modem Configuration

5.2.1. Add a New Modem

If there is no "Standard 19200 bps Modem" has been installed, it needs to add a new standard modem to
the modem section of the control panel.
UC20_PPP_Application_Note Confidential / Released 14 / 29
