Quick Guide

This guide describes the basic printing procedures using this
machine. In the next pages, the procedures for each step and
particular cautions are explained.
For safe and correct use, be sure to read Safety Information
before using the machine.
1

Smoothing wrinkles/flattening fibers

To print clearly, use the optional finisher to smooth wrinkles and flatten fibers.
2

Loading the fabric in the tray

Turn the machine on, and then detach the tray.
Load in the tray the fabric you want to print on such as a T-shirt or tote bag.
When loading the fabric, align the vertical direction of the fabric with the print direction in the
application.
Load the fabric so that it does not stick out of the tray.
3
Printing
Load the tray into the machine, and then click [Print] on the application on the tablet device or the
computer.
4
Fixing ink
Attach the protective cover to the tray. Detach the tray, and then use the optional finisher to fix
ink to the fabric.
Do not touch ink that has not fixed.
DYX025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ri 100 Pink and is the answer not in the manual?

Questions and answers

Summary of Contents for Ricoh Ri 100 Pink

  • Page 1: Quick Guide

    Quick Guide This guide describes the basic printing procedures using this machine. In the next pages, the procedures for each step and particular cautions are explained. For safe and correct use, be sure to read Safety Information before using the machine. DYX025 Smoothing wrinkles/flattening fibers To print clearly, use the optional finisher to smooth wrinkles and flatten fibers.
  • Page 2 Smoothing wrinkles/flattening fibers Use the optional finisher to smooth wrinkles and flatten fibers. Loading the fabric in the tray DSA197 DSA221...
  • Page 3 DSA053 Direction of image and fabric Portrait image (T-shirt) DSB427 Landscape image (tote bag) DSB428...
  • Page 4 Use the optional finisher to fix ink. For reference, in the case of a commercially available heat press, ink was fixed at 330°F (approx. 165°C) in 90 seconds. © 2017, 2018 Ricoh Co., Ltd. EN GB EN US EN AU...

This manual is also suitable for:

Ri 100Ri 100 green
