Quick Guide

This guide describes the basic printing procedures using the
printer and this machine. In the next pages, the procedures
for each step and particular cautions are explained.
For safe and correct use, be sure to read Safety Information
before using the machine.
Guide to Components of the Finisher
Front Cover
Mode Switching
Lever
Control Panel
Mode indicator
*1
• Light: Press the [Preheat] key to start preheating
• Flashing: Preheating under way
• Off: Preheating completed
Cassette
Time/temperature indicator
[Temperature] key
Finisher
(This machine Rh 100)
[Preheat] key
*1
[Fixing Time] key
[Stop/Unlock] key
DSA121
Printer
(Ri 100)
[Power] key
DSB130
