KMC Controls STE-9000 Series Installation Manual

INTRODUCTION
Complete the following steps to mount a KMC Conquest
STE-9000 Series Digital NetSensor and connect it to a
Conquest BAC-59xx/9xxx Controller.
STE-92xx/95xx
STE-90xx/93xx
with Motion Sensor
NOTE: See the Conquest NetSensors STE-9000
Series Digital Room Sensors
and the Conquest Selection Guide
kmccontrols.com
other information.
SELECT MOUNTING LOCATION
See the Room Sensor and Thermostat Mounting
Location and Maintenance Application Guide
cautions, troubleshooting, and best practices.
NOTE: Complete rough-in-wiring at each location
before installing a sensor.
REMOVE BACKPLATE
1. Turn the hex screw
1
until the screw clears the cover.
KMC Controls, 19476 Industrial Drive, New Paris, IN 46553
STE-9000 Series NetSensors
STE-9xxxW-NDL
(no display)
data sheet
at
for specifications and
for
clockwise into the sensor
1
NOTE: The hex screw
backplate.
2. Pull the cover from the backplate.
CONNECT ETHERNET CABLE
3. Feed the Ethernet patch cable
Conquest controller through the center of the
backplate
4
NOTE: The Ethernet patch cable should be a
maximum of 150 feet (45 meters).
4. Mount the backplate on an electrical box using the
screws provided.
NOTE: If additional thermal insulation is needed,
install the optional
between the backplate and the electrical
box. For more information, see the
Sensor and Thermostat Mounting Location
and Maintenance Application Guide.
/ 877.444.5622 / Fax: 574.831.5252
Installation Guide
should remain in the
2
from the
3
.
4
3
HPO-9002 gasket
/ www.kmccontrols.com
2
Room
