Teledyne Pioneer DVL Getting Started

Getting Started with the Pioneer DVL

Verify all parts are present

Step
1
The standard DVL includes:

Install the Software and Documentation

Step
2
The Documentation and Software CD includes:

Communication and Power Setup

Step
3
See the reverse side of this guide for detailed
instructions.

Read the Integration Guide

Step
4
Included with the system is a printed
copy of the Integration Guide.

PRODUCT FEATURES:

•
Bottom-tracking capability for deep water operations:
1000-4500 meter depth rating for tracking ranges
100-275 m
•
Compact DVLs that can be packaged into small portable
UUVs of 7.5 inches (<19 cm) in diameter
•
Flexible triggering with both trigger in and trigger out
•
Multiple communications channels, allowing for
optimum connectivity with external sensors
•
Upgradeable to include ADCP capabilty
•
Real-time current pro ling option provides additional
critical data parameters from a single instrument
TELEDYNE RD INSTRUMENTS
•
Pioneer DVL with Dummy Plugs
• Power/Comm Cable and Pigtail cable
• Shipping case
• Spare Parts Kit
• Software and Documentation CD
• Printed copy of Getting Started and Integration Guide
• Check packing slip for additional options
• TRDI Toolz and RDI Tools software
• Pioneer DVL Guide PDF
• Pioneer Getting Started PDF
• Pioneer Integration Guide PDF
