VFI2 — Visual Fault Identifier
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
WAVELENGTH: 650nm
MAX OUTPUT: 1.0mw
PULSE RATE: 2Hz, 50% DUTY
IEC 60825-1: 2007-03
Featuring two modes of operation, continuous wave
(CW) and 2Hz modulation, the VFI2 visible red laser
source is designed to troubleshoot faults on fiber
optic cables.
Warning! The VFI2 is a registered Class II Laser
Product. Never look directly into optical output.

Buttons

ON/OFF
Press and hold about 2 sec. to turn on (green LED
will illuminate)
Press to turn off
2Hz
Press to toggle CW and 2Hz modes
— in the CW mode the red LED is off
— in the 2Hz mode the red LED is on

Inspecting Cables

Note: Clean connectors on cables before connecting
them to VFI2.
Attach the inspected cable to the 2.5 mm Universal
adapter
Turn the VFI2 on and observe the inspected cable
for faults
