Stiga SDNSL 108 Hydro Operator's Manual

Ride-on lawnmower with seated operator
Hide thumbs
Table of Contents

Advertisement

Quick Links

171506263/1EN
06/2018
SDNSL 108 Hydro
IT
Tosaerba con conducente a bordo seduto - MANUALE DI ISTRUZIONI
ATTENZIONE: prima di usare la macchina, leggere attentamente il presente libretto.
EN
Ride-on lawnmower with seated operator - OPERATOR'S MANUAL
WARNING: read thoroughly the instruction booklet before using the machine.

Advertisement

Table of Contents
loading

Related Manuals for Stiga SDNSL 108 Hydro

Summary of Contents for Stiga SDNSL 108 Hydro

  • Page 1 171506263/1EN 06/2018 SDNSL 108 Hydro Tosaerba con conducente a bordo seduto - MANUALE DI ISTRUZIONI ATTENZIONE: prima di usare la macchina, leggere attentamente il presente libretto. Ride-on lawnmower with seated operator - OPERATOR’S MANUAL WARNING: read thoroughly the instruction booklet before using the machine.
  • Page 3 ITALIANO - Istruzioni Originali ....................ENGLISH - Translation of the original instruction ................
  • Page 4 Type: /min Art.N. - s/n Transmission max xxx N (xx kg)
  • Page 6 OK ! NO !
  • Page 9 H = 0 mm H = 10 mm H = 20 mm H = 30 mm max 10˚(17% )
  • Page 12 110 mm...

  • Page 14: Dati Tecnici

    �1� DATI TECNICI SDNS 108 Hydro �2� Potenza nominale * 6,4 ÷ 14,6 �3� Giri al minuto * 2800 ± 100 �4� Impianto elettrico 13 x 5,00-6 �5� Pneumatici anteriori (15 x 5,00-6) �6� Pneumatici posteriori 20 x 8,50-8 Pressione gonfiaggio anteriore 13 x 5,00-6 �7�...

  • Page 15: Technical Data

    �1� TECHNICAL DATA SDNS 108 Hydro �2� Nominal power (*) 6,4 ÷ 14,6 �3� RPM (*) 2800 ± 100 �4� Electrical system 13 x 5,00-6 �5� Front tyres (15 x 5,00-6) �6� Rear tyres 20 x 8,50-8 Front tyre pressure 13 x 5,00-6 �7�...
  • Page 16 WARNING!: READ THOROUGHLY THE INSTRUCTION BOOKLET BEFORE USING THE MACHINE. Keep for future reference INDEX 1. GENERAL INFORMATION ......2 8.4 Electronic circuit board ......17 2. SAFETY REGULATIONS ......2 8.5 Replacing a fuse ......... 17 3. GETTING TO KNOW THE MACHINE ... 4 8.6 Replacing bulbs ........

  • Page 17: General Information

    how to stop the engine quickly. Failure 1. GENERAL INFORMATION to follow the warnings and instructions may result in fire and/or serious injury. HOW TO READ THE MANUAL • Never allow children or persons unfamiliar with these instructions to Some paragraphs in the manual contain use the machine.

  • Page 18: During Operation

    • Do not smoke when filling up with • Pay attention on sloping ground which fuel or when handling the fuel. requires particular care to prevent overturning • Use a funnel to top up with or loss of control of the machine. The fuel only in the open air.

  • Page 19: Maintenance & Storage

    Use limitations 2.5 ENVIRONMENTAL PROTECTION • Never operate the machine with guards damaged, missing or incorrectly Safeguarding the environment must be a relevant assembled (grass catcher, side discharge and priority aspect of machine use, of benefit to guards rear discharge guards) the community and the environment we live in.

  • Page 20: Safety Signs

    The use of special attachments provided for Warning: Read the instruc- by the Manufacturer as original equipment or tions before operating the which may be purchased separately, allows this machine. work to be done in various operating modes, Warning: Disconnect the illustrated in this manual or the instructions key and read the instructions that accompany the single attachments.

  • Page 21: Main Components

    5. Serial number in the factory and have to be assembled after 6. Article code unpacking. Follow the instructions below. 7. Weight in kg 8. Type of transmission Unpacking and completing the assembly should be done on a flat and stable surface, Write the identification data of the with enough space for machine handling machine in the specific space on the...
  • Page 22 3. Attach the front bumper (fig. 8.E) to the 4.2 STEERING WHEEL ASSEMBLY brackets (fig. 8.A) and (fig. 8.B) using the screws (fig. 8.F) and nuts (fig. 8.G). 1. Put the machine on a flat surface and straighten the front wheels. 4.6 MOUNTING THE CUTTING- 2.

  • Page 23: Brake Pedal

    IMPORTANT Before disassembling or ser- NOTE When moving from one area vicing the deflector, always push the safety lever to another, put the lever in a position (Fig. 16.B) and lift the side unloading guard (Fig. between «tortoise» and «hare». 16.A) to allow disassembly.

  • Page 24: Using The Machine

    5.6 HYDROSTATIC TRANSMISSION 5.9 CUTTING HEIGHT ADJUSTER LEVER DISENGAGEMENT LEVER Use this lever to raise and lower the This lever has two positions, as cutting-means assembly to one of the 7 shown on the plate (fig. 12.L): different cutting heights (fig. 12.G). 1.

  • Page 25: Safety Checks

    6.1.3 Tyre pressure 6.2.1 General safety check Having the right tyre pressure is the main Object Result condition for ensuring that the cutting-means Battery No damage to the casing, assembly is horizontal and mows evenly. cover or terminals Side discharge guard Good condition.

  • Page 26: Using On Slopes

    9. Release the ignition key once IMPORTANT Always bear in mind that the engine has started. the safety devices prevent the engine from 10. If cold starting: as soon as the starting if safety requirements have not engine ticks over regularly: been met.
  • Page 27 The machine already slows down considerably less frequently, higher grass and weeds by just releasing the drive pedal (par. 5.5) start growing (clover and daisies, etc.). 2. It is always better to cut the grass when dry. 3. The cutting means must be in good 6.5.3 Reverse gear condition and well sharpened so that the grass is cut straight without a ragged...

  • Page 28: After Operation

    2. switch off the engine by turning table will help you maintain your machine’s the ignition key to Off; safety and performance. It lists the main 3. with the engine turned off, close the maintenance tasks and how often they need fuel tap (fig.
  • Page 29 3. Disconnect the tube (fig. 25.A) installed 6. Fully tighten holding the extension on the fuel filter inlet (fig. 25.B). tube firmly in place (fig. 26.A). 4. Open the fuel tap (if provided) 7. Clean up any spills. 5. Collect the fuel in a suitable container. 6.

  • Page 30: Nuts And Bolts

    • before leaving the machine disused for IMPORTANT Never use hose-nozzles or harsh a long period (over 30 days) (par. 9); detergents for cleaning the body and engine! • before starting up the machine after a prolonged period of inactivity. 7.5.2 Cleaning the cutting- Carefully read and observe the battery means assembly...
  • Page 31 If mowing is uneven, check the 8.3.2 Choice and positioning of the tyre pressure (par. 6.1.3). jack on the rear wheels If this is not sufficient to achieve an even cut, please contact your Dealer to adjust the Position some wooden wedges (fig. 29.A) alignment of the cutting-means assembly.

  • Page 32: Electronic Circuit Board

    IMPORTANT Check that the two rear wheels REAR AXLE are the same height (fig. 35.A) and that the difference between the external diameters of • This is a sealed single unit that does not the two wheels (fig. 35.B) is no greater than require maintenance.

  • Page 33: Assistance And Repairs

    – fasten firmly to the means of transport using workshop for servicing, assistance ropes or chains to prevent it from tipping and safety device inspection. over causing damage and fuel leaks. 12. WARRANTY COVERAGE 11. ASSISTANCE AND REPAIRS The warranty covers all material and This manual provides all the necessary manufacturing defects.
  • Page 34 Operation Frequency Completed (Date or Hours) Notes (hours) Checking for any damage to the After each machine. If necessary, contact the authorised assistance centre. Before Battery power reserve par. 7.6 storage Complete bolt and screw check Cutting means positioning and sharpening check Transmission belt check Cutting means control belt check Brake regulation and check...

  • Page 35: Problem Identification

    14. PROBLEM IDENTIFICATION PROBLEM PROBABLE CAUSE REMEDY 1. With the key turned to Turn the ignition key to «STOP» position «START» the starter and look for the cause of the problem: motor does not run starting conditions have not been met check that all starting conditions are met (par.
  • Page 36 8. Unusual vibrations cutting-means assembly is full of grass clean the cutting-means while working assembly (par. 7.5.2) the cutting means are contact your Dealer unbalanced or loose loose bolts and screws check and tighten all the engine and frame bolts 9.
  • Page 37 © by STIGA S.p.A. IT • Il contenuto e le immagini del presente manuale d’uso sono stati realizzati per conto di STIGA S.p.A. e sono tutelati da diritto d’autore – E’ vietata ogni riproduzione o alterazione anche parziale non autorizzata del documento.
