Headers and TestPoints
PCI
56 testpoints are supplied each labeled with the PCI signal attached. Some names
are truncated to allow larger easier to read print.
JTAG
TRST, TDI, TDO, TMST, TCK plus a 3.3V and a Ground reference to interface
with the installed PMC via the JTAG signals.
GND
8 Ground testpoints are spaced along the top of the PCI signals to support Logic
Analyzer and Ocilloscope reference. Each are labeled GND.
Embedded Solutions
Page 6
