Order Information

standard temperature range -40ó85
PMC-UNIV-TEST
HDEterm68
HDEcabl68
All information provided is Copyright Dynamic Engineering
ø
C
Vertical mount component side forward PMC adapter
into PCI. 32 bit universal voltage PCI bus interface.
Testpoints on PCI, JTAG signals. Impedance
controlled, matched length routing. SCSI connector
differentially routed to Pn4 for rear IO applications.
-ROHS [ROHS compliant parts and process]
-ENG add second connector set, remove SCSI,
switch headers to A side.
http://www.dyneng.com/PMC-UNIV-TEST.html
http://www.dyneng.com/HDEterm68.html
68 pin SCSI II to 68 screw terminal converter with DIN
rail mounting.
http://www.dyneng.com/HDEcabl68.html
SCSI cables with latch blocks or thumbscrews and
various lengths are available. Custom lengths can be
ordered.
