- Page 1 DICKSON VFC70/VFC21 Vaccine Temperature Chart Recorder Operation Contents: Product Applications and Useful Features Product Specifications Operating Instructions / Getting Started Charts & Accessories Calibrations Troubleshooting Warranty / Factory Service & Returns VFC21 VFC70 Rev. 04/08...
- Page 2 The CDC now recommends using continuous, certified and calibrated chart recorders for vaccine storage monitoring. Dickson has designed the chart recorder specifically for vaccine storage applications. Easy-to- read charts clearly show when vaccines go out of acceptable temperature range and for how long. This unique chart recorder highlights ranges for standard refrigerator vaccines (35 to 46°F) and freezer vaccines...
-
Page 3: Product Specifications
Product Specifications Measurement Ranges: VFC70: 0 to +70°F; VFC21: -18 to +21°C Ambient Operating Temperature: -22 to +122°F (-30 to +50°C); 0-95% RH (non-condensing) Pen Accuracy: ±2% full scale Display Accuracy: ±3.6˚F (±2˚C) Temperature Sensor: Precise spiral-wound bi-metallic strip transducer Power Supply: One “AA”... -
Page 4: Getting Started
Getting Started • Place a new chart on recorder. • Set time by inserting a coin into chart hub and turning clockwise until the current hour is referenced to the time indicator. (Time Indicator is directly to the right and below the pen tip). •... - Page 5 Charts (for current pricing go to www.dicksonweb.com or call 1-800-323-2448) Model Range 7 Day Chart VFC70 0 to +70°F C203 VFC21 C204 -18 to +21°C Accessories (for current pricing go to www.dicksonweb.com or call 1-800-323-2448) Description Order # NIST Traceable Calibration 3-pt. (new unit) N300 A2LA Accredited Calibration 3-pt.
- Page 6 (a high, medium, and low) on new units only. • N400 - Deluxe A2LA Accredited NIST Traceable Calibration 3-Point: ISO Guide 25/A2LA Documentation of 3 pre-selected points of as found data before and after calibration for Dickson temperature and/or humidity instrumentation on new units only. •...
-
Page 7: Troubleshooting
Dickson shall not be liable for consequential or incidental damages resulting from failure or malfunction of its products. Dickson makes no warranty for products not manufactured by it or for any products modified by buyer, or subject to misuse or neglect.
