Dickson KT6 Manual

Temperature chart recorder
Hide thumbs Also See for KT6:

Advertisement

Table of Contents

See also: Operating Manual , Manual
DICKSON
KT6
Temperature Chart Recorder
Contents:
Product Specifications
Operating Instructions, Alarm Relays & Display Symbols
Charts & Accessories
Instrument Anatomy
Getting Started / Installation
Keypad Operation
Dip Switch Setup & Calibration
Troubleshooting, Warranty / Factory Service & Returns
Order Form
Rev. 07/04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KT6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dickson KT6

Summary of Contents for Dickson KT6

  • Page 1 DICKSON Temperature Chart Recorder Contents: Product Specifications Operating Instructions, Alarm Relays & Display Symbols Charts & Accessories Instrument Anatomy Getting Started / Installation Keypad Operation Dip Switch Setup & Calibration Troubleshooting, Warranty / Factory Service & Returns Order Form Rev. 07/04...

  • Page 2: Product Specifications

    Product Specifications KT655 KT603 Temperature Ranges 0 to -100°F/C, 0 to -50°F /C, -50 to 50°F/C, 0 to 50°F/C, (user selectable): 50 to 100°F/C, 0 to 100°F/C, 0 to 250°F/C Recorder Accuracy: ±.5% of chart range and ±1.8°F (1°C) Recorder only Standard K-Thermocouple (other temperature sensor types Sensor Compatibility: available on special order)

  • Page 3: Operating Information

    (see “Specifications”). 1. Open the door of the recorder by depressing the door latch. Pens (2 pen KT6): 2. Press the “HOME” key The blue pen has a longer pen arm than the red 3. Lift the chart, if there is one present, to fully pen.
  • Page 4 Charts & Accessories (for current pricing go to www.dicksonweb.com or call 1-800-323-2448) Range 24 Hour Chart 7 Day Chart -50 to +50°F/C C652 C651 0 to ±50°F/C C654 C653 0 to ±100°F/C C658 C657 0 to +250°F/C C660 C659 0 to +500°F/C C662 C661 50 to +100°F/C...
  • Page 5 Instrument Anatomy Dip Switches Digital Display Dip Switch Chart Guide Pen Assembly (optional) Setting Chart Clips Figure 1 Door Latch Pen Cap Holders 9V Battery Chart Hub Keypad Time Arrow Compartment Panel Mount Holes Figure 2 Key Hole/Wall Input Jack 0-5V/ Mount Holes 0-20mA K-Thermocouple Jack...

  • Page 6: Getting Started

    3. Remove the protective pen cap from red pen “Instrument Anatomy) Installation Before you install your KT6 recorder, read through this Wall Mount: Keyhole slots are provided on the KT6 for entire manual to find out about all the options that are wall mounting. available to you.

  • Page 7: Keypad Operation

    If the pen is located outside the chart, press the procedure as in step #2 for setting the “HOME” key to move pen to recording position. maximum alarm setting. If your KT6 only has Press the “HOME” key with the pen in recording one pen go to step 6.

  • Page 8: Dip Switch Setup

    Dip Switch Setup To set up the KT6 for your specific application, you #7 OFF might need to change some of the Dip Switches. 0 to 250˚ #5 ON The switches are located under the chart in the #6 ON lower half of the dial plate.

  • Page 9: Troubleshooting

    Dickson shall not be liable for consequential or incidental damages resulting from failure or malfunction of its products. Dickson makes no warranty for products not manufactured by it or for any products modified by buyer, or subject to misuse or neglect.
