Temptek CF Series Instruction Manual page 5

CF Series Portable Chiller : Air & Water-Cooled : 5 - 40 Tons
7.0 RELATED DRAWINGS
7.1 Mechanical Schematic : Water-Cooled : 5 - 10 Tons
7.2 Mechanical Schematic : Water-Cooled : 15 - 40 Tons
7.3 Mechanical Schematic : Air-Cooled : 5 - 10 Tons
7.4 Mechanical Schematic : Air-Cooled : 15 - 30 Tons
7.5 Typical Electrical : Air-Cooled
7.6 Typical Electrical : Water-Cooled
7.7 Typical Physical : Air-Cooled : 5 Tons
7.8 Typical Physical : Air-Cooled : 7.5 - 10 Tons
7.9 Typical Physical : Air-Cooled : 15 - 20 Tons Fan Cooled
7.10 Typical Physical : Air-Cooled : 15 - 30 Tons Blower
7.11 Typical Physical : Air-Cooled : 5 - 10 Tons With Remote Condenser
7.12 Typical Physical : Air-Cooled : 15 - 30 Tons With Remote Condenser
7.13 Typical Physical : Water-Cooled : 5 Tons
7.14 Typical Physical : Water-Cooled : 7.5 - 10 Tons
7.15 Typical Physical : Water-Cooled : 15 - 30 Tons
7.16 Typical Physical : Water-Cooled : 40 Tons
7.17 Duct Schematic for Air-Cooled Chillers
8.0 APPENDIX
8.1 Operations below 48°F fluid or 38°F ambient
8.2 Operating with glycol (antifreeze) and with a set point above 48°F
or below 38°F ambient
8.3 Refrigerant pressure-temperature chart
8.4 Inhibited propylene glycol
8.5 Chiller capacity and derate chart
TEMPTEK, INC.
525 East Stop 18 Road Greenwood, Indiana 46142
317-887-6352 Fax: 317-881-1277
Email: service@Temptek.com
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
80
81
82
82
Page: 5
