CF Series Portable Chiller : Air & Water-Cooled : 5 - 40 Tons
Instrument
Transformer
Terminal Strip
Pump Starter
Pump Overload
Block
Grounding Bus Bar
Typical electrical panel prior to October 2015.
Instrument
Transformer
Terminal Strip
Pump Starter and
Overload Block
Grounding Bus Bar
Typical electrical panel after October 2015.
TEMPTEK, INC.
525 East Stop 18 Road Greenwood, Indiana 46142
317-887-6352
Fax: 317-881-1277
Email: service@Temptek.com
Transformer:
Line Voltage to
115 volts
Power Entry Terminal Block
Pump & Transformer Fusing
Ground Lug
Compressor & Fan Contactor
Transformer: Line Voltage
to 115 volts
Power Entry Terminal Block
Pump & Transformer Fusing
Compressor & Fan Contactor
