I.O.M. #187 updated 02/18/2021
INSTRUCTION MANUAL
BG-N4 Series
G l y c o l
Stop: If running at a fluid temperature below 48°F or if the chiller will be installed in a climate
where the ambient temperature may get below 40°F you must use a water and glycol mixture
at a ratio that protects the fluid from freezing to approximately 25°F below the lowest expected
set point temperature or the lowest expected ambient temperature whichever is lower. See
Section 8.1 and 8.2 of this manual before operating your chiller. Regular testing of your glycol
protection is critical.
Model:
Serial Number :
• INSTALLATION • OPERATION • MAINTENANCE
C h i l l e r
525 East Stop 18 Road Greenwood, IN 46142
317-887-6352 fax: 317-881-1277
Service Department fax: 317-885-8683
E-mail: sales@Temptek.com
TEMPTEK, INC.
www.Temptek.com
Advertisement
Table of Contents
Related Manuals for Temptek BG-N4 Series
Summary of Contents for Temptek BG-N4 Series
- Page 1 I.O.M. #187 updated 02/18/2021 INSTRUCTION MANUAL • INSTALLATION • OPERATION • MAINTENANCE BG-N4 Series G l y c o l C h i l l e r Stop: If running at a fluid temperature below 48°F or if the chiller will be installed in a climate where the ambient temperature may get below 40°F you must use a water and glycol mixture...
- Page 3 C h i l l e r INSTRUCTION MANUAL MG INSTRUMENT With & SCROLL COMPRESSORS AIR-COOLED MODELS COVERING INSTALLATION OPERATION MAINTENANCE TEMPTEK, INC. 525 East Stop 18 Road Greenwood, IN 46142 Phone: 317-887-6352 Fax: 317-881-1277 Service Department fax: 317-885-8683 www.Temptek.com e-mail: sales@Temptek.com...
-
Page 4: Table Of Contents
MAINTENANCE Warranty service procedure Periodic preventative maintenance Special maintenance Pump seal service Checking the refrigerant charge Proper cleaning procedure for brazed plate evaporators TEMPTEK, INC. Page: 4 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... - Page 5 Chiller capacity and derate chart Standard MG Instrument Settings Probe Calibration : MG Instrument Status Indicators : MG Instrument Water Quality Modbus Registers 8.10 Remote & Auto Start Feature Configuration 73 TEMPTEK, INC. Page: 5 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com...
- Page 6 THIS PAGE INTENTIONALLY BLANK Page: 6...
-
Page 7: General
BG-N4 Glycol Chiller GENERAL Introduction Safety Receiving Instructions 1.4 Efficiency Clean Air Act Water Treatment TEMPTEK, INC. Page: 7 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 8: Introduction
Observe all safety precautions during installation, startup and service of this equipment due to the presence of high voltage and refrigerant charge. Only qualified personnel should install, startup and service this equipment. TEMPTEK, INC. Page: 8 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277... - Page 9 4. This symbol is seen on all chillers to alert user to the danger of the refrigeration system under pressure. System should only be serviced by a licensed technician. TEMPTEK, INC. Page: 9 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com...
-
Page 10: Receiving Instructions
Customers should implement a refrigerant management program to document the type and quantity of refrigerant in each chiller. All refrigeration service technicians performing work on this chiller must be licensed and certified. Vent all refrigerant relief valves in accordance to ANSI/ASHRAE Standard 15. TEMPTEK, INC. Page: 10 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... - Page 11 Do not use deionized water in this unit. Some customized units may be compatible with deionized water. Consult the factory before using deionized water. TEMPTEK, INC. Page: 11 525 East Stop 18 Road Greenwood, Indiana 46142...
- Page 12 THIS PAGE INTENTIONALLY BLANK Page: 12...
-
Page 13: Installation
BG-N4 Glycol Chiller INSTALLATION General Unit Location To and From Process Connections Air Cooled Condenser Installation Electrical Connection TEMPTEK, INC. Page: 13 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 14: General
8 feet from the walls. If multiple units are placed side by side a TEMPTEK, INC. Page: 14 525 East Stop 18 Road Greenwood, Indiana 46142... -
Page 15: To And From Process Connections
Typical wye strainer - Not recommended. From Process To Process 10 ton unit show. Typical process connections shown. TEMPTEK, INC. Page: 15 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 16: Air-Cooled Condenser
Condenser Air Filtering. Use a filter that produces very low air flow restrictions. Generally a disposable fiberglass filter with a MERV rating of 2 - 3 provides adequate air filtration. The purpose of the filter is to prevent large particles such as dust, lint and debris from fouling the condenser. You should be able to see through the filter media. Using restrictive filter media can cause loss of chiller capacity, difficulty running in warm weather and fan motor overheating. Typical Filter materials. TEMPTEK, INC. Page: 16 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 17: Electrical Connection
Use of incorrect voltage will void the unit’s warranty and cause a significant hazard that may result in serious personal injury and unit damage. TEMPTEK, INC. Page: 17 525 East Stop 18 Road Greenwood, Indiana 46142... - Page 18 Disconnect power before servicing. Follow all facility lock-out tag-out procedures. WARNING: Electric Shock Hazard. High Voltage is present in the electrical cabinet. Disconnect power before servicing. Follow all facility lock-out tag-out procedures. TEMPTEK, INC. Page: 18 525 East Stop 18 Road Greenwood, Indiana 46142...
- Page 19 BG-N4 Glycol Chiller Transformer Power Entry / Disconnect (optional) Typical electrical panel shown Compressor Starter Coolant Pump Stater TEMPTEK, INC. Page: 19 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com...
- Page 20 THIS PAGE INTENTIONALLY BLANK Page: 20...
-
Page 21: Operations
Instrument : Utilities Menu Instrument : Network Menu Instrument : Flow Menu (optional) Instrument : Options Menu 3.10 Instrument : Machine Menu 3.11 Shut Down Procedure TEMPTEK, INC. Page: 21 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 22: General
These units will normally have an “R” in the model number. Example: BGD-10AR is referred to as “reverse flow”. See Section 6.3.J for more information. Please note, Sections 3.2.A & 5.4 are not applicable for reverse flow units. TEMPTEK, INC. Page: 22 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... - Page 23 Supply electrical power to the unit. Once the correct voltage is supplied to the unit, the POWER switch on the unit’s control panel will illuminate. Adjust the setpoint to 70°F or higher to prevent the compressor from activating during this procedure. TEMPTEK, INC. Page: 23 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com...
- Page 24 PROCESS FLOW ADJUSTMENTS The operator must determine and set proper water flow rate for the most efficient and trouble free operation. Water flow rate through the process is determined by the pressure losses in the process loop. Generally, higher flow rates result in turbulent flow achieving maximum temperature control and lower maintenance. Since the evaporator in most liquid chillers is flow sensitive, the efficiency of operation is directly related to the flow of liquid. TEMPTEK, INC. Page: 24 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com...
- Page 25 If the low pressure gauge reading is below normal, reduce the pressure on the spring to provide more bypass. TEMPTEK, INC. Page: 25 525 East Stop 18 Road Greenwood, Indiana 46142...
- Page 26 BG-N4 Glycol Chiller Automatic Low Flow Bypass Valve HIGH FLOW: If a high flow condition is present: High flow can cause premature component wear and poor operating conditions. Adjust the flow so that an 8°F - 10°F rise in water temperature is indicated while the system is fully loaded. TEMPTEK, INC. Page: 26 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com...
-
Page 27: Mg Instrument Operations
Contact your local refrigeration contractor or the factory for further information. The operating range of the chiller control may be changed to 0°F - 90°F by adjusting the Setpoint Configuration. Refer to Section 3.10.d of this manual for more information. TEMPTEK, INC. Page: 27 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... - Page 28 S e t p o i n t : 50°F S e t p o i n t : 50°F Circulating Circulating Suction 151 PSI TEMPTEK, INC. Page: 28 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com...
- Page 29 50 seconds out of every 60 seconds. The instrument will turn off the compressor and capacity control system when the To Process temperature is 4 degrees or more below the setpoint. TEMPTEK, INC. Page: 29 525 East Stop 18 Road Greenwood, Indiana 46142...
-
Page 30: Instrument : Main Menu
S e t p o i n t : 50°F S e t p o i n t : 50°F Circulating Circulating Circulating Back Pick Cancel Adjust Acknowledge TEMPTEK, INC. Page: 30 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... - Page 31 The factory default is 0 GPM. The range for the Low Flow is from 0 to 100 GPM. Once acknowledged, press the Back button repeatedly to return to the Setpoints screen or press the home button to return to the Home screen. TEMPTEK, INC. Page: 31 525 East Stop 18 Road Greenwood, Indiana 46142...
-
Page 32: Instrument : Utilities Menu
• From Process ... displayed in Fahrenheit and Celsius • Process Probe Temperature ... displayed in Fahrenheit and Celsius (optional) • MCU Temperature ... displayed in Fahrenheit and Celsius TEMPTEK, INC. Page: 32 525 East Stop 18 Road Greenwood, Indiana 46142... -
Page 33: Instrument : Network Menu
Cancel Adjust Acknowledge Press the Select button to select Protocol. Use the Up or Down arrow buttons to select the preferred protocol. Use the Select button to save the selection and confirm success. TEMPTEK, INC. Page: 33 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 34: Instrument : Flow Menu (Optional)
S e t p o i n t : 50°F S e t p o i n t : 50°F Circulating Circulating Circulating Circulating Back Pick Back Pick Back Acknowledge Pick TEMPTEK, INC. Page: 34 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 35: Instrument : Options Menu
S e t p o i n t : 50°F Circulating Circulating Circulating Circulating Back Back Pick Pick Back Pick Back Acknowledge Pick TEMPTEK, INC. Page: 35 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 36: Instrument : Machine Menu
48°F requires appropriate Set Time levels of glycol. Min Setpoint Hi Temp Shutdown Cancel Units Con rm Back Select Back Pick Back Adjust TEMPTEK, INC. Page: 36 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... - Page 37 Units Back Pick Back Adjust Acknowledge Use the Up or Down arrow keys to select the Unit display and then press the Select button to save and confirm success. TEMPTEK, INC. Page: 37 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com...
- Page 38 Changes are recorded in the instrument memory and adjusting these parameters could void the Factory warranty. • Secondary Pump • Chiller Type • Cooling Source TEMPTEK, INC. Page: 38 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277...
-
Page 39: Shut Down Procedure
To shut down the unit and disconnect from the process: Turn off the unit. Disengage the electrical supply to the chiller at the disconnecting device. Disconnect all process lines. TEMPTEK, INC. Page: 39 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... - Page 40 THIS PAGE INTENTIONALLY BLANK Page: 40...
-
Page 41: Troubleshooting
Shuts Off On Low Pressure Compressor Shuts Off On Internal Overload Low Or No Process Pressure Or Water Flow Cooling Capacity Inadequate Sensor Pumps 4.10 Chiller Controller TEMPTEK, INC. Page: 41 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 42: Unit Will Not Start
Repair or replace motor if defective. Improperly set high pressure control. Have refrigeration serviceman adjust pressure setting in control instrument as directed by factory service. TEMPTEK, INC. Page: 42 525 East Stop 18 Road Greenwood, Indiana 46142... -
Page 43: Shuts Off On Low Pressure
Pump. Check pump for correct rotation. Check pump suction for restriction. Replace motor if defective. Filters. Check filter in the chilled water circuit and clean if necessary. Pressure switch (or flow switch). Readjust or replace if defective. Fuses and wiring. Have electrician check the fuses and wiring. TEMPTEK, INC. Page: 43 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277... -
Page 44: Cooling Capacity Inadequate
It contains the software and electronic components which operate the control instrument. The control instrument is not field repairable. It can be easily removed and replaced or repaired if a problem occurs. All control instruments used in these water chillers are covered by the machine’s warranty. Proprietary “tailor made” instrument are manufactured specifically by our affiliated company Advantage Electronics. TEMPTEK, INC. Page: 44 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... - Page 45 Purchase a new instrument and repair the old one as a back up. Do not disassemble the instrument. Other Information Repair Warranty: 1 year. Ship to: Temptek Engineering 525 East Stop 18 Road Greenwood, IN 46143 Attention: Repairs. (317-887-0729) Include in box: part, purchase order, contact name, phone number, symptom (if available).
- Page 46 THIS PAGE INTENTIONALLY BLANK Page: 46...
-
Page 47: Maintenance
MAINTENANCE Warranty Service Procedure Periodic Preventative Maintenance Special Maintenance \Pump Seal Service Checking The Refrigerant Charge Proper Cleaning Procedure For Brazed Plate Evaporator TEMPTEK, INC. Page: 47 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 48: Warranty Service Procedure
Refrigerant sight glass: Check for bubbles when compressor is operating at 100%. Check the moisture indicator for a color other than green. Clean unit. SPECIAL MAINTENANCE Any service of the refrigeration system must be accomplished by a certified refrigeration technician. TEMPTEK, INC. Page: 48 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... - Page 49 BG-N4 Glycol Chiller Addition of compressor oil. Addition of refrigerant. Repair of a refrigerant leak. Adjustment of super heat. Changing of filter-drier or drier core. Repair of a refrigeration solenoid. TEMPTEK, INC. Page: 49 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com...
-
Page 50: Pump Seal Service
The motor shaft is free to rotate, but must be secured to remove the impeller. To secure the motor shaft, insert a flat bladed screw driver in Separating Motor Figure 5.5E TEMPTEK, INC. Page: 50 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277... - Page 51 When the pump seal replacement procedure is complete, the operator may restart the unit according the section 3. Stationary Member Figure 5.5J Replacing Impeller Figure 5.5K TEMPTEK, INC. Page: 51 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com...
-
Page 52: Checking The Refrigerant Charge
Turn off all power to the machine. For chillers with a reservoir tank, drain the tank to below the evaporator outlet. For chillers without a reservoir tank, drain total TEMPTEK, INC. Page: 52 525 East Stop 18 Road Greenwood, Indiana 46142... - Page 53 SEWER OR DRAIN CONTAINER) FREON OUT ORIGINAL WATER OUT PORT BACKFLUSH WATER IN PORT (SUPPLY BACKFLUSHING WATER FLOW TO THIS PORT) FREON IN TEMPTEK, INC. Page: 53 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com...
- Page 54 THIS PAGE INTENTIONALLY BLANK Page: 54...
-
Page 55: Components
BG-N4 Glycol Chiller COMPONENTS Water System Refrigeration System Options TEMPTEK, INC. Page: 55 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 56: Water System
EXPANSION VALVE: The expansion valve throttles flow of refrigerant liquid into the evaporator and creates a pressure drop in the refrigerant system that allows the liquid refrigerant to “boil off” inside the evaporator. TEMPTEK, INC. Page: 56 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277... -
Page 57: Options
Audible Alarm: A simple buzzer alarm emits a loud alarm. Visual Alarm: Emits an audible sound and flashes a beacon. CONDENSER SCREEN: Optional for air-cooled models only. The condenser screen is a filter for the air-cooled condenser to prevent air borne solids and debris from clogging the TEMPTEK, INC. Page: 57 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... - Page 58 System water make-up and level control is accomplished externally at the process since the chiller contains no reservoir. TEMPTEK, INC. Page: 58 525 East Stop 18 Road Greenwood, Indiana 46142...
-
Page 59: Related Drawings
BG-N4 Glycol Chiller RELATED DRAWINGS Typical Mechanical Schematic TEMPTEK, INC. Page: 59 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 60: Typical Mechanical Schematic
• Provides efficient operation in ambient conditions to -20°F High Flow Pump • Required when ambient condition may be below 50°F Glycol Reservoir • Includes flooding control valves and liquid receiver TEMPTEK, INC. Page: 60 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277... -
Page 61: Appendix
Chiller capacity and derate chart Standard MG Instrument Settings Probe Calibration : MG Instrument Status Indicators : MG Instrument Water Quality Modbus Registers 8.10 Remote & Auto Start Feature Configuration TEMPTEK, INC. Page: 61 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 62: Operations Below 48°F Fluid Or 38°F Ambient
In your chilling system that can mean higher energy costs, high pumping costs, and possibly even shut downs for system cleaning. We recommend the use of DowFrost or Monsanto DFS-1. TEMPTEK, INC. Page: 62 525 East Stop 18 Road Greenwood, Indiana 46142... -
Page 63: Inhibited Propylene Glycol
-5°F to -6°F. Usa a Misco or equivalent to test your glycol on a regular basis. Misco Products Model #7084VP 1-800-358-1100 TEMPTEK, INC. Page: 63 525 East Stop 18 Road Greenwood, Indiana 46142... -
Page 64: Refrigerant Pressure-Temperature Chart
BG-N4 Glycol Chiller REFRIGERANT PRESSURE-TEMPERATURE CHART TEMPTEK, INC. Page: 64 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 65: Chiller Capacity And Derate Chart
Ambient conditions affect air cooled chiller operation and capacity. Standard rating is at 95°F entering air temperature. For ambient air conditions greater than 95°F, chiller derating will occur. For ambients over 95°F consult factory. TEMPTEK, INC. Page: 65 525 East Stop 18 Road Greenwood, Indiana 46142... -
Page 66: Standard Mg Instrument Settings
• 9 PSI to 150 PSI Adjustable Low Pressure Cut In Range • 19 PSI to 150 PSI Adjustable High Pressure Cut Out Range • 225 PSI to 580 PSI TEMPTEK, INC. Page: 66 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277... -
Page 67: Probe Calibration : Mg Instrument
When the two temperatures are equal, the calibration procedure is complete. NOTE: the optional “from process” probe has its own calibration potentiometer. If calibration of this probe is required, repeat the setup and calibration procedure TEMPTEK, INC. Page: 67 525 East Stop 18 Road Greenwood, Indiana 46142... - Page 68 From Process Calibration Potentiometer To Process Calibration Potentiometer From Process Calibration Potentiometer To Process Calibration Potentiometer TEMPTEK, INC. Page: 68 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com...
-
Page 69: Status Indicators : Mg Instrument
10 seconds indicating proper compressor operation. Compressor On Pulse Screw Compressor Compressor Compressor at 50% Capacity at 75% Capacity TEMPTEK, INC. Page: 69 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... -
Page 70: Water Quality
Although not mandatory, distilled water would be an excellent choice for filling the system. Corrosion Corrosion is usually the result of acidic water (improper PH control). This can be controlled by proper chemical treatment. TEMPTEK, INC. Page: 70 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com... - Page 71 BG-N4 Glycol Chiller Algae Algae (organism growth) can be controlled by the proper use of chemical treatment. TEMPTEK, INC. Page: 71 525 East Stop 18 Road Greenwood, Indiana 46142 317-887-6352 Fax: 317-881-1277 Email: service@Temptek.com...
-
Page 72: Modbus Registers
