RL78/G1G
Sensorless Speed control of 120-degree conducting controlled permanent
magnetic synchronous motor (Implementation)
Summary
This application note aims at explains sample programs driving a permanent magnetic synchronous motor in the 120-
degree conducting method using the RL78/G1G microcontroller.
These control programs are only to be used as reference and Renesas Electronics Corporation does not guarantee the
operations. Please use them after carrying out a thorough evaluation in a suitable environment.
Operation checking device
Operations of the control programs have been checked by using the following device.
RL78/G1G (R5F11EBAAFP)
Target control programs
The target control programs of this application note are as follows.
RL78G1G_MRSSK_SPM_LESS_120_CSP_CA_V100 (IDE：CS+ for CA,CX)
RL78G1G_MRSSK_SPM_LESS_120_CSP_CC_V100 (IDE：CS+ for CC)
RL78G1G_MRSSK_SPM_LESS_120_E2S_CC_V100 (IDE：e
RL78/G1G Sensorless 120-degree conducting control program for
Reference
RL78/G1G Group User's Manual: Hardware (R01UH0499EJ0130)
Application note: '120-degree conducting control of permanent magnetic synchronous motor: algorithm'
(R01AN2657EJ0120)
Renesas Solution Starter Kit 24V Motor Control Evaluation System for RX23T User's Manual
(R20UT3697EJ0100)
R01AN3582EJ0100 Rev.1.00
Jan 13, 2017
24V Motor Control Evaluation System and RL78/G1G CPU CARD
APPLICATION NOTE
2
studio)
R01AN3582EJ0100
Rev.1.00
Jan 13, 2017
Page 1 of 46
