WARNING
Potential for Fire, Smoke and Asphyxiation Hazards
Incorrect installation, adjustment, or misuse of this burner could result in death, severe
personal injury, or substantial property damage.
To the Homeowner or Equipment
Owner:
Please read and carefully follow all instructions
provided in this manual regarding your responsibilities
in caring for your heating equipment.
Contact a professional, qualifi ed service agency for
installation, start-up or service work.
Save this manual for future reference.
Form 6104BCF5 R09, Printed in the USA 01/08
To the Professional, Qualifi ed Installer
or Service Agency:
Please read and carefully follow all instructions provided
in this manual before installing, starting, or servicing this
burner or heating system.
The Installation must be made in accordance with all state
and local codes having jurisdiction.
1
Advertisement
Table of Contents
Related Manuals for Beckett CF 500/800
Summary of Contents for Beckett CF 500/800
- Page 1 WARNING Potential for Fire, Smoke and Asphyxiation Hazards Incorrect installation, adjustment, or misuse of this burner could result in death, severe personal injury, or substantial property damage. To the Homeowner or Equipment Owner: Please read and carefully follow all instructions provided in this manual regarding your responsibilities in caring for your heating equipment.
-
Page 2: Table Of Contents
Your Beckett burner will provide years of effi cient operation if it is professionally installed and maintained by a qualifi ed service technician. If at any time the burner does not appear to be operating properly, immediately contact your qualifi... -
Page 3: Hazard Defi Nitions
Hazard defi nitions Indicates an imminently hazardous situation, which, if not avoided, will result in death, serious injury, or property damage. Indicates a potentially hazardous situation, which, if not avoided, could result in death, severe personal injury, and/or substantial property damage. Indicates a potentially hazardous situation, which, if not avoided, may result in person-... -
Page 4: Owner's Responsibility
Clearances With the burner installed in the appliance, there must be adequate space in front of and on the sides of the burner to allow access and operation. Verify that the clearance dimensions comply with all local codes and with the appliance manufacturer’s recommendations. -
Page 5: Fuel Supply
If fuel supply is below the fuel unit — Use a two-pipe oil system when the fuel unit must lift the oil more than 8 feet if burner is equipped with a B fuel unit. The return line provided by the two-pipe system is needed to purge the air from the fuel lines and minimize the likelihood of air-related problems during operation. -
Page 6: Verify Burner Components
fi ring rate for the burner depends on the length of the fi ring chamber and the distance from the burner center to the chamber fl oor. Verify that the chamber dimensions are at least as large as the minimum values given in Figure 2. -
Page 7: Stray Light Lockout
The control must detect a dark, no-fl ame condition in order to start the burner or it will hold in the stray light lockout mode. Shield the burner from direct exposure to intense light. -
Page 8: Mount Air Tube To Burner
Mount air tube to burner Insert the air tube into the burner housing. Carefully align the the four screw holes. Attach the air tube to the burner using the four provided screws. Install nozzle Install the oil nozzle in the nozzle adapter. Use a 3/4”... -
Page 9: Fuel Unit By-Pass Plug
Size the oil supply and return lines using the guidelines given in the fuel unit literature included in the literature envelope. Oil line fl ow rate will equal the burner rate for one-pipe systems. For two-pipe systems, refer to Table 2 for the fuel unit gear set capacity - the rate at which fuel is recirculated when connected to a two-pipe system. -
Page 10: Wire The Burner
Recycle — If the fl ame is lost while the burner is fi ring, the control shuts down the burner, enters a 60-second recycle de- lay, and then repeats the ignition steps outlined above. -
Page 11: Prepare The Burner For Start-Up
Do not attempt to start the burner unless you are fully qualifi ed. Do not continue with this procedure until all items in the “Prepare the burner for start-up”... -
Page 12: Initial Air Settings
Oil-Flooded Appliance: Shut off the electrical power and the oil supply to the burner and then clear all ac- cumulated oil before continuing. If the condition still appears unsafe, contact the Fire Department. -
Page 13: Cad Cell Resistance Check
CAD cell resistance check While the burner is fi ring, and after the ignition has been turned off, press and release the reset button (hold 1/2 sec- ond or less) to check the cad cell resistance. The LED will fl... -
Page 14: Maintenance And Service
fi re. Do not tamper with the burner or controls or make any adjustments unless you are a trained and qualifi ed service technician. To ensure continued reliable operation, a qualifi ed service technician must service this burner annually. -
Page 15: Replacement Parts
Replacement parts Item Part Name/Description Air Tube Spline Nut Adjusting plate assembly Blocking Oil Solenoid Valve Igniter Control Air Band Air Shutter Fuel Pump Fuel lines Head Assembly: CF500 - KK CF800 - KH (Tube A) CF800 - KJ (Tube B) Electrode Assembly Nozzle Line Assembly Motor - 1/3 PSC... -
Page 16: Limited Warranty Information
Beckett Burners, Beckett-branded major components and non-Beckett-branded major components that came as original equipment on a Beckett burner or were sold as a replacement part by Beckett should be returned, freight prepaid, to Beckett’s home office. Credit will be issued to the customer unless the returned equipment is determined by Beckett to be out of warranty or damaged by user, in which case the equipment will be scrapped.
