Beckett CF3500 Specifications

BECKETT
CF3500
COMMERCIAL OIL BURNER
Specifi cations
Fuels U.S. #1 or #2 heating oil only (ASTM D396)
Canada #1 stove oil or #2 furnace oil only
CRANKCASE OIL, OR ANY OIL
CONTAINING GASOLINE.
Firing Range 17.0 to 35.0 gph
Motor 2 HP 3450 rpm
208/230/60 Hz Standard
13.4 amps @ 230 VAC
Optional Voltages:
208, 230, 480, 575 VAC/3-PH,
50 or 60 Hz
Ignition Trans. Continuous Duty, 120V/12,000V
Housing Cast aluminum
Fuel Unit 100 to 300 psig
Oil Nozzle 45
to 70
o o
Features
S - Standard O - Optional
On/Off
Linkageless Low/High/Low or Low/High/Off
Air Proving Switch
Direct Spark Ignition of Main Flame
Flame Safeguard with UV Sensor or Light Sensor
Customized Electrical Cabinet
UL/CUL - CSD1 - XL GAPS
1
FM
IRI (old standard)
www.beckettcorp.com
DO NOT USE
GASOLINE,
Solid
N/A - Not Available
N/A
S
S
S
O
O
S
O
O

Overall Dimensions

22.5
7.88
8.00
12.7
Typical Burner Sequence of Operation - 7505
2
Valve-on
Delay
8
Motor-off
Delay
Two-pipe Oil Flow
200 - 300
PSIG
200 - 300
PSIG
28.0 Min.
39.0 Max.
9
1
Pump
Standby
Prime
3 4
Trial for
Lockout
Ignition
5
Ignition
Carryover
6 7
Run Recycle
R.W. Beckett Corporation ● Elyria, Ohio
5.3
14.7
