Potential for Fire, Smoke and Asphyxiation Hazards
Incorrect installation, adjustment, or misuse of this burner could result in death, severe
personal injury, or substantial property damage.
To the Homeowner or Equipment Owner:
Please read and carefully follow all instructions
provided in this manual regarding your
responsibilities in caring for your heating
equipment.
Contact a professional, qualifi ed service agency for
installation, start-up or service work.
Save this manual for future reference.
COMMERCIAL PRODUCTS
To the Professional, Qualifi ed Installer or Service Agency:
Please read and carefully follow all instructions provided
in this manual before installing, starting, or servicing this
burner or heating system.
The Installation must be made in accordance with all state
and local codes having jurisdiction.

Advertisement

Table of Contents
loading

Related Manuals for Beckett CULUS CF1400

Summary of Contents for Beckett CULUS CF1400

  • Page 1 Potential for Fire, Smoke and Asphyxiation Hazards Incorrect installation, adjustment, or misuse of this burner could result in death, severe personal injury, or substantial property damage. To the Homeowner or Equipment Owner: Please read and carefully follow all instructions provided in this manual regarding your responsibilities in caring for your heating equipment.

  • Page 2: Table Of Contents

    Your Beckett burner will provide years of effi cient oper- ation if it is professionally installed and maintained by a qualifi ed service technician. If at any time the burner does not appear to be operating properly, immediately contact your qualifi...

  • Page 3: General Information

    Never attempt to burn any fuel not specifi ed and approved for use in this burner. Never restrict the air inlet openings to the burner or the combustion air ventilation openings in the room. If the facility is unattended in severely cold weather,...

  • Page 4: Pre-Installation Checklist

    Clearances With the burner installed in the appliance, there must be adequate space in front of and on the sides of the burner to allow access and operation. Verify that the clearance dimensions comply with all local codes and with the appliance manufacturer’s recommendations.

  • Page 5: Electrical Supply

    Electrical Supply Verify that the power connections available are correct for the burner. Refer to Figure 1. All power must be supplied through fused disconnect switches. Figure 1 – Typical Nameplate General Model Information...

  • Page 6: Verify Air Tube

    Section: Pre-Installation Checklist Figure 2 - Dimensions: Minimum Combustion Chamber and Air Tube Mounting. * Install burner with 1/4” ± 1/8” *2° Minimum Dimensions Firing Model Rate Refractory Lined (gph) CF1400 0 to 5 7.0” 25.0” 5 to 10 8.0”...

  • Page 7: Stray Light

    ○ The control must detect a dark, no-fl ame condition in order to start the burner or it will hold in the stray light lockout mode. ○ Shield the burner view window from direct exposure to intense light.

  • Page 8: Mount Air Tube To Burner

    Remove the rear access door from the back of the burner for improved access to the interior. Attach the air tube to the burner with the bolts and acorn nuts provided. The acorn nuts must go on the outside of the burner, with the bolts inserted from the inside.

  • Page 9: Set "Z" Dimension

    See Figure 8. Install the pedestal support kit (recommended) by attaching the 3/4” NPT fl ange (item a) to the bottom of the burner using the (4) #10 screws provided. Cut and thread (one end only) a 3/4” pipe nipple (item b) with length 11 inches less than dimension D in Figure 8.

  • Page 10: One-Pipe Oil System By-Pass Loop

    Section: Mount the Burner Special Note: The burner is shipped with a by- pass plug installed in the fuel unit. For low/high operation, the by-pass plug must be left in the fuel unit, regardless of the fuel system used (one-pipe with by-pass loop or two-pipe).

  • Page 11: Wire The Burner

    Perform all wiring in compliance with the National Electric Code ANSI/NFPA 70 (Canada CSA C22.1). Install the burner and all wiring in accordance with the National Electrical Code and all applicable local codes or requirements.
  • Page 12 The burner is then sent to Motor-off Delay. Recycle: If the fl ame is lost while the burner is fi ring, the control shuts down the burner, enters a 60 second recycle delay, and repeats the ignition sequence.
  • Page 13 Section: Wire the Burner CF1400/CF2300 Burner Manual...

  • Page 14: Typical Burner Sequence Of Operation - 7184B Control

    The burner is then sent to Motor-off Delay. Recycle — If the fl ame is lost while the burner is fi ring, the control shuts down the burner, enters a 60-second recycle delay, and then repeats the ignition steps outlined above.

  • Page 15: Prepare The Burner For Start-Up

    Do not attempt to start the burner unless you are fully qualifi ed. Do not continue with this procedure until all items in the “Prepare the burner for start-up”...

  • Page 16: Initial Head Position

    (Figure 16). ○ Slide the secondary adjusting plate (item the rear of the burner until the number on the indicator plate corresponds to the initial head setting given in for the desired fi ring rate Tables 4a and 4b and burner (high-fi...

  • Page 17: Initial Air Settings

    Equipment Manufacturer) application, the “Mfr’s Settings” label (see Figure 1) will indicate the application and the initial air settings made at Beckett. Please verify those settings using the following procedure. If your burner was not built for a specifi ed application,...

  • Page 18: Start The Burner

    Cad Cell Resistance Measurement: If the Beckett 7505 control is equipped with the GeniSys Display Module, part 52067U, the cad cell resistance can be selected and read on the LCD screen. Also, the GeniSys Contractor Tool, part 52082U, can be used for this purpose.

  • Page 19: Operating The Burner

    If the CO is less than 11% (O decrease the air and check the smoke level. Operate the burner from low fi re to high fi re and back to verify operation. Turn the burner off. Wait one or two minutes (for chamber to clear) and then turn on again to verify starting characteristics.

  • Page 20: Annual Service

    fi re. Do not tamper with the burner or controls or make any adjustments unless you are a trained and qualifi ed service technician. To ensure continued reliable operation, a qualifi ed service technician must service this burner annually.
  • Page 21 Section: Replacement Parts Figure 19a – Burner Replacement Parts SK9930 SK9931 CF1400/CF2300 Burner Manual...
  • Page 22 Blower wheel Motor Mounting Flange Motor Motor relay (not shown) Adjustable fl ange * These doors are NOT interchangeable. Please specify when ordering. Beckett replacement parts Description Mounted on Junction Box All models w/ cast aluminum door w/ stamped sheet-metal door...
  • Page 23 Figure 19b – Burner Replacement Parts (Continued) SK9930 SK9936 SK9932 CF1400/CF2300 Burner Manual...

  • Page 24: Limited Warranty Information

    The R. W. BECKETT CORPORATION (“Beckett”) warrants to persons who purchase its “Products” from Beckett for resale, or for incorporation into a product for resale (“Customers”), that its equipment is free from defects in material and workmanship. To qualify for warranty benefi ts, products must be installed by a qualifi...

This manual is also suitable for:

Cf2300

Table of Contents
