Bill of Materials

The following table lists the bill of materials for the LX8204 evaluation board.
Table 2 • Bill of Materials
Item Part Type
1 Miscellaneous Components
2 Miscellaneous Components
3 Miscellaneous Components
4 Miscellaneous Components
5 Miscellaneous Components
6 Capacitors
7 Capacitors
8 Resistors
9 Resistors
Part Description
Microsemi IC—LX8204
Test point (J3)
Terminal
Jumper/2-pin
2N7002
1 µF/50 V/10%/0805/X5R
33 µF/25 V/10%/0805/X5R
500 kΩ/1%/0805
100 kΩ/1%/0805
Microsemi Proprietary and Confidential. User Guide Revision 1.0
Reference Qty
U1 1
EN/FAULT 1
VIN, VOUT, GND 3
J2 1
Q5 1
C16 1
C8 1
R1 1
R9 1
