LX8204 12 V E-Fuse Evaluation Board
5
PCB Layout of Evaluation Board
The LX8204 evaluation board is a four-layer board. The following illustrations depict each of the board's
four layers.
Figure 2 • Layer 1: Top Layer
Figure 3 • Layer 2: Ground Layer
Microsemi Proprietary and Confidential. User Guide Revision 1.0
5
