Portal > Knowledgebase > Telephone >
9611G IP Phone User's Guide
9611G IP Phone User's Guide
Michael Wagner - 2018-02-07 -
0 Comments
- in
Telephone

Scrolling and Navigation

A navigation icon appears in the phone display to indicate that you can scroll to more
options or information. Use the right and left navigation arrows to go to other screens when
the paging icon (left- and right-facing arrows) displays on the Title Line or to move the
cursor right or left when entering text.
The softkey labels will change according to the options available for the selected line. The
OK button is a shortcut for the default action. For example, when you select an entry in
your contacts list, pressing the OK button places a call to that person.

Avaya Menu

You can use the Avaya Menu to adjust and customize options and settings for your

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9611G and is the answer not in the manual?

Questions and answers

Related Manuals for Avaya 9611G

Summary of Contents for Avaya 9611G

  • Page 1: Scrolling And Navigation

    OK button is a shortcut for the default action. For example, when you select an entry in your contacts list, pressing the OK button places a call to that person. Avaya Menu You can use the Avaya Menu to adjust and customize options and settings for your...
  • Page 2 Network Information shows a summary of network-related parameters for your phone and provides diagnostic information. VPN Settings VPN Settings are unused at this time. About Avaya one-X Basic information about your telephone Answering and making a call Answering a call...
  • Page 3 Press Resume or the line button of the held call to retrieve the call. Transferring a call From the Phone screen, if the call to be transferred is not already active (highlighted), select the line on which the call to be transferred appears. Press Transfer.

  • Page 4: Conference Calls

    Dial *7 or press the Call Pickup speed dial button (if configured by I.T.). Begin talking immediately. Conference Calls The 9611G Voice Over IP telephone only supports conference calls of up to 6 parties (You and 5 others). If you need a larger conference call, you can order a MeetMe conference here.

  • Page 5: Call History

    Press Call to call the person or press More, and then Edit to edit contact information. Calling a person from the contacts list Press the Contacts button. Select the person or primary number you want to call. Locate the contact you want by starting to type the person’s name as it is listed. Press Call or OK.
  • Page 6 To remove a letter, press the BKSP button. The on-phone Directory The Avaya 9611G IP phone has the option to have an on-phone telephone directory for on- campus extensions. This feature must be enabled by I.T. The on-phone directory information is based on Caller-ID information, so some people may not appear in the on- phone directory.
  • Page 7 Once you have found the person in the directory to which you'd like to place a call, press the Make Call button, or press Exit and dial the number manually. Related Pages Identifying your telephone...
