Halsey Taylor HydroBoost HTHBHVR8 Owner's Manual

Factory prep bottle filling station and cooler
Hide thumbs Also See for HydroBoost HTHBHVR8:

Advertisement

Quick Links

Download this manual
HTHBHVR8-NF*1A, *2A, *3A
HTHBHVR-NF*A, *2A
HTHBHVR8*1A, *2A, *3A
HTHBHVR*A, *2A
Owners Manual
HTHBHVR8, HTHBHVR8-25, HTHBHVR8-26 Factory Prep
HydroBoost
Bottle Filling Station and Cooler
®
IMPORTANT
THIS IS AN INDOOR APPLICATION ONLY.
ALL SERVICE TO BE PERFORMED BY AN
AUTHORIZED SERVICE PERSON.
Model HTHBHVR8
Page 1
98986C (Rev. M - 12/17)

Advertisement

loading
Need help?

Need help?

Do you have a question about the HydroBoost HTHBHVR8 and is the answer not in the manual?

Questions and answers

Related Manuals for Halsey Taylor HydroBoost HTHBHVR8

Summary of Contents for Halsey Taylor HydroBoost HTHBHVR8

  • Page 1 HTHBHVR8-NF*1A, *2A, *3A HTHBHVR-NF*A, *2A HTHBHVR8*1A, *2A, *3A HTHBHVR*A, *2A Owners Manual HTHBHVR8, HTHBHVR8-25, HTHBHVR8-26 Factory Prep HydroBoost Bottle Filling Station and Cooler ® IMPORTANT THIS IS AN INDOOR APPLICATION ONLY. ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON. Model HTHBHVR8 Page 1 98986C (Rev.

  • Page 2: Tools Required

    HTHBHVR8-NF*1A, *2A, *3A HTHBHVR-NF*A, *2A HTHBHVR8*1A, *2A, *3A HTHBHVR*A, *2A TOOLS REQUIRED BUT NOT PROVIDED: SAFETY GLASSES GLOVES ELECTRIC DRILL 3/4” WRENCH OR CRESCENT WRENCH UTILITY KNIFE TAPE MEASURE PENCIL CENTER PUNCH 1/2” SOCKET & RATCHET WRENCH 5/32” ALLEN WRENCH IMPORTANT! INSTALLER PLEASE NOTE THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC.
  • Page 3 HTHBHVR8-NF*1A, *2A, *3A HTHBHVR-NF*A, *2A HTHBHVR8*1A, *2A, *3A HTHBHVR*A, *2A Note: Danger! Electric shock hazard. Disconnect power before servicing unit. Pictured is unit only without Bottle Filler Uses HFC-134A refrigerant See Fig. 8 17, 18 See Fig. 7 See Fig. 9 See Fig.
  • Page 4 HTHBHVR8-NF*1A, *2A, *3A HTHBHVR-NF*A, *2A HTHBHVR8*1A, *2A, *3A HTHBHVR*A, *2A Fig. 2 98986C (Rev. M - 12/17) Page 4...
  • Page 5 HTHBHVR8-NF*1A, *2A, *3A HTHBHVR-NF*A, *2A HTHBHVR8*1A, *2A, *3A HTHBHVR*A, *2A MOUNTING TOP COVER SCREWS BOTTLE FILLER MOUNTING BRACKET FOR FASTENING UNIT MOUNTING SCREWS TO WALL DO NOT REMOVE MOUNTING SCREWS DO NOT REMOVE NOTE: TRIM PLATES MUST BE INSTALLED ON THE INSIDE OF THE BOTTLE FILLER SIDE PANEL SLOTS.
  • Page 6 HTHBHVR8-NF*1A, *2A, *3A HTHBHVR-NF*A, *2A HTHBHVR8*1A, *2A, *3A HTHBHVR*A, *2A REMOVAL OF BOTTLE FILLER FOR SERVICING 1) Turn off the water supply to the Water Cooler. Unplug and/or turn off Circuit Breaker to Cooler and Bottle Filler. NOTE: the Lower Front Panel of the cooler(s) may need to be removed. To prevent scratching the basin place a towel or soft cloth over the entire basin when working above it.
  • Page 7 HTHBHVR8-NF*1A, *2A, *3A HTHBHVR-NF*A, *2A HTHBHVR8*1A, *2A, *3A HTHBHVR*A, *2A PUSH BUTTON MECHANISM Fig. 7 Basin Fig. 9 VANDAL RESISTANT BUBBLER DETAIL Fig. 8 Page 7 98986C (Rev. M - 12/17)
  • Page 8 HTHBHVR8-NF*1A, *2A, *3A HTHBHVR-NF*A, *2A HTHBHVR8*1A, *2A, *3A HTHBHVR*A, *2A BF9 PROGRAM SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE SETTING UNIT TYPE 1) To verify the software program of the control board the 1) Depress the program button for approximately 2 seconds unit will need to be shut down and restarted.
  • Page 9 HTHBHVR8-NF*1A, *2A, *3A HTHBHVR-NF*A, *2A HTHBHVR8*1A, *2A, *3A HTHBHVR*A, *2A BF11 - BF12 PROGRAM SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE Continued from below: 1) To verify the software program of the control board the unit will 2) When the display changes to “SETTINGS”, depress the button again. need to be shut down and restarted.
  • Page 10 HTHBHVR8-NF*1A, *2A, *3A HTHBHVR-NF*A, *2A HTHBHVR8*1A, *2A, *3A HTHBHVR*A, *2A WATERSENTRY PLUS FILTER PARTS LIST ® ITEM PART NO. DESCRIPTION 55898C Filter Assy-3000 Gallon (Single) 55898C_12PK Filter Assy-3000 Gallon (12 Pack) 98926C Kit-Filter Head Fittings-includes John Guest Fittings Assy-Filter Head & Brkt includes Filter Head/ 1000003563 Mtg Brkt/John Guest Ftgs/Screws WATER FILTER EXPLODED VIEW...

  • Page 11: 115V Wiring Diagram

    HTHBHVR8-NF*1A, *2A, *3A HTHBHVR-NF*A, *2A HTHBHVR8*1A, *2A, *3A HTHBHVR*A, *2A 115V PARTS LIST ITEM PART NO. DESCRIPTION BOTTLE FILLER REPLACEMENT PART KITS 97446C Bubbler Assy - VR PART NO. DESCRIPTION 98777C Kit - Compressor Mtg/Clips/Studs/Grommets 98775C Kit - Fan Motor/Blade/Shroud/Nut/Screws 98543C Kit - Electrical Package 36322C...
