Installation/Care/Use Manual
HTHB Surface Mount Bottle Filling Station
Installer
To assure you install this model easily and correctly,
PLEASE READ THESE SIMPLE INSTRUCTIONS BEFORE STARTING THE
INSTALLATION. CHECK YOUR INSTALLATION FOR COMPLIANCE WITH ALL
PLUMBING, ELECTRICAL AND OTHER APPLICABLE CODES. FOLLOW ALL
WARNINGS AND CAUTIONS CAREFULLY. After installation, leave these instructions
with the customer for future reference.
Warnings
1. Use with clean, clear, fresh potable drinking water only! Do not use with water that is microbiologically
unsafe or of unknown quality without adequate disinfection before the system.
2. Connect Power Cord only to a grounded three prong electrical outlet with electrical power that:
a. MUST be rated for this product as specified on product data label.
b. MUST have over-current protection (e.g. Fuse, Breaker).
c. MUST have Ground Fault Circuit Interrupt protection (GFCI).
d.
These products are designed to operate on 20 to 105 psig supply line pressure. If inlet pressure is
above 105 psig, a pressure regulator must be installed in supply line. Any damage caused
by reason of connecting this product to supply line pressure lower than 20 psig or higher than
105psig is not covered by warranty
HTHBSM-1A, HTHBSMWF-1A
THIS IS AN INDOOR APPLICATION ONLY!
ALL SERVICE TO BE PERFORMED BY AN
AUTHORIZED SERVICE PERSONNEL.
TOOLS/ITEMS REQUIRED
BUT NOT SUPPLIED
- SERVICE STOP VALVE WITH 3/8"
COMPRESSION OUTLET
- FASTENERS FOR WALL TYPE (8 REQ'D.)
- SLIP JOINT DRAIN UNION OR
COMPRESSION CLAMP
- 5/32" HEX-WRENCH
.
Page 1
IMPORTANT
98765C (Rev. C - 9/11)
Advertisement
Related Manuals for Halsey Taylor HTHB Series
Summary of Contents for Halsey Taylor HTHB Series
- Page 1 HTHBSM-1A, HTHBSMWF-1A Installation/Care/Use Manual HTHB Surface Mount Bottle Filling Station IMPORTANT THIS IS AN INDOOR APPLICATION ONLY! ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSONNEL. TOOLS/ITEMS REQUIRED BUT NOT SUPPLIED - SERVICE STOP VALVE WITH 3/8" COMPRESSION OUTLET - FASTENERS FOR WALL TYPE (8 REQ’D.) - SLIP JOINT DRAIN UNION OR COMPRESSION CLAMP...
- Page 2 HTHBSM-1A, HTHBSMWF-1A, ROUGH-IN HTHBSM, HTHBSM-WF 17 13/16" 453mm 8 3/16" 208mm 7" 7" 178mm 178mm 5 3/8" 136mm 9 1/2" 241mm 25 7/16" 646mm 2 7/8" 73mm 12" 305mm 46 7/16" 1180mm 3 1/16" 77mm 34 7/16" 875mm 8 7/8" 6 1/4"...
-
Page 3: Installation Instructions
HTHBSM-1A, HTHBSMWF-1A INSTALLATION INSTRUCTIONS Pre-Installation (reference Rough-In, Fig. 1) 1. Ensure Wall is structurally sound to bear the loads imparted by the HydroBoost Surface Mount Bottle ™ Filling Station (On-Wall Bottle Filler). If necessary, install a Wall Support Carrier (not supplied). 2. - Page 4 HTHBSM-1A, HTHBSMWF-1A, Plumbing Connections • Ensure lines and ports remain clean and free of contaminants during assembly. • Purge each component if necessary. • To ensure quick-connect connections seal properly, follow instructions per Figure 2. Connect Plumbing Lines Connect water supply line to unit: 1.1.
- Page 5 HTHBSM-1A, HTHBSMWF-1A BF9 PROGRAM SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE SETTING UNIT TYPE 1) To verify the software program of the control board the 1) Depress the program button for approximately 2 seconds unit will need to be shut down and restarted. The chiller until the display changes then release.
-
Page 6: Replacement Part Kits
HTHBSM-1A, HTHBSMWF-1A, ® WATERSENTRY PLUS FILTER PARTS LIST (See Fig. 4) ITEM NO. PART NO. DESCRIPTION Filter Head Assy. 51294C Screw #8-18 x .75 PH 70792C 70823C Fitting - Superseal 3/8” (10 mm) 70822C Fitting - Superseal 1/4” (6 mm) NOTE: SCREW THE LOCKNUT 55898C Filter Assy...
