HACFSCWSD*1F
HACFSCWSDNF*1F
HAC8FSCWSQ*1F
HAC8FSCWSNFQ*1F
Owners Manual
MANUAL DEL PROPIETARIO HALSEY TAYLOR
MANUEL DE L'UTILISATION HALSEY TAYLOR
Hydroboost
Bottle Filling Station and Cooler
®
Estación de llenado de botella Hydroboost
y enfriador
®
Station de remplissage de bouteille Hydroboost
et refroidisseur
®
Patent zurn-elkay.com/patents
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ADVERTENCIA: Cáncer y daño reproductivo - www.P65Warnings.ca.gov
AVERTISSEMENT: Cancer et effets néfastes sur la reproduction - www.P65Warnings.ca.gov
Page 1
1000001728 (Rev. R - 03/21)
Advertisement
Related Manuals for Halsey Taylor Hydroboost HACFSCWSDNF 1F Series
Summary of Contents for Halsey Taylor Hydroboost HACFSCWSDNF 1F Series
- Page 1 HACFSCWSD*1F HACFSCWSDNF*1F HAC8FSCWSQ*1F HAC8FSCWSNFQ*1F Owners Manual MANUAL DEL PROPIETARIO HALSEY TAYLOR MANUEL DE L'UTILISATION HALSEY TAYLOR Hydroboost Bottle Filling Station and Cooler ® Estación de llenado de botella Hydroboost y enfriador ® Station de remplissage de bouteille Hydroboost et refroidisseur ®...
- Page 2 HACFSCWSD*1F HACFSCWSDNF*1F HAC8FSCWSQ*1F HAC8FSCWSNFQ*1F Note: Danger! Electric shock hazard. Disconnect power before servicing unit. Nota: peligro! Peligro de descarga eléctrica. Desconecte antes de reparar la unidad. Remarque : Danger ! Risque d'électrocution. Débrancher avant de réparer l'appareil. Pictured is unit only without bottle filler. Uses HFC-134A refrigerant Usa refrigerante HFC-134A Utilise du fluide frigorigéne HFC-134A...
- Page 3 HACFSCWSD*1F HACFSCWSDNF*1F HAC8FSCWSQ*1F HAC8FSCWSNFQ*1F Fig. 2 Page 3 1000001728 (Rev. R - 03/21)
- Page 4 HACFSCWSD*1F HACFSCWSDNF*1F HAC8FSCWSQ*1F HAC8FSCWSNFQ*1F IMPORTANT IMPORTANTE MPORTANT ALL SERVICE TO BE PERFORMED BY AN TODO EL SERVICIO DEBERÁ SER EFECTUADO POR TOUT ENTRETIEN DOIT ÊTRE EFFECTUÉ PAR AUTHORIZED SERVICE PERSON UNA PERSONA DE SERVICIO AUTORIZADA UN REPRÉSENTANT AUTORISÉ HANGER BRACKETS & TRAP INSTALACIÓN DE FIJADOR DE INSTALLATION DU SIPHON ET DU INSTALLATION...
- Page 5 HACFSCWSD*1F HACFSCWSDNF*1F HAC8FSCWSQ*1F HAC8FSCWSNFQ*1F PUSH BAR MECHANISM MECANISMO DE BARRA DE EMPUJE MÉCANISME DU BOUTON-POUSSOIR 26 B Fig. 5 LEGEND/LEYENDA/LÉGENDE Water Valve Mechanism - ADJUSTMENT PROCEDURE: A) Note: Water flow direction - Turn adjustment screw “Counter-Clockwise” until water flow Nota: Dirección del flujo de agua from bubbler starts.
- Page 6 HACFSCWSD*1F HACFSCWSDNF*1F HAC8FSCWSQ*1F HAC8FSCWSNFQ*1F MOUNTING 7/16” BOLT HOLES FOR SCREWS FASTENING UNIT TO WALL TOP COVER UNIT CENTER LINE Fig. 6 Fig. 7 BRACKET & SCREWS Fig. 8 Fig. 9 Bottle Filler Installation Instructions 1) Remove two (2) mounting screws with 5/32” Allen wrench holding top cover to Bottle Filler (See Fig. 7). Remove top cover. Note do not discard mounting screws, they will be needed to reinstall top cover.
- Page 7 HACFSCWSD*1F HACFSCWSDNF*1F HAC8FSCWSQ*1F HAC8FSCWSNFQ*1F BF11 - BF12 PROGRAM SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE Continued from below: 1) To verify the software program of the control board the unit will 2) When the display changes to “SETTINGS”, depress the button again. need to be shut down and restarted.
- Page 8 HACFSCWSD*1F HACFSCWSDNF*1F HAC8FSCWSQ*1F HAC8FSCWSNFQ*1F BOTTLE FILLING UNIT WALL MOUNTING PLATE Fig. 11 Fig. 10 Fig. 12 220V/240V Detail 220V PARTS LIST/ 220V LISTA DE PIEZAS/ 220V LISTE DES PIÈCES ITEM PART NO. DESCRIPTION DESCRIPCIÓN DESCRIPTION Compressor Serv. Pak (220v/50Hz) Compresor Paquete de servicio (220v/50Hz) Kit d’Entretien du Compresseur (220v/50Hz) 1000002147 1000002146...
- Page 9 HACFSCWSD*1F HACFSCWSDNF*1F HAC8FSCWSQ*1F HAC8FSCWSNFQ*1F Superseal Fitting Assembly Supersello Accesorio de Montaje Superseal Montage Assemblage Note: Screw the locknut hand tight to seal. Nota: Apriete la mano de la contratuerca para sellar. Remarque : Visser la main de l'écrou de blocage pour assurer l'étanchéité.
- Page 10 HACFSCWSD*1F HACFSCWSDNF*1F HAC8FSCWSQ*1F HAC8FSCWSNFQ*1F PARTS LIST/ LISTA DE PIEZAS/ LISTE DES PIÈCES ITEM PART NO DESCRIPTION DESCRIPCIÓN DESCRIPTION 22897C Panel - Bottom Dispenser Panel- Dispensador Inferior Panneau - Distributeur Inférieur 23003C Bracket - Regulator Mounting Fijador-Montaje Regulador Support - Montage du Régleur 28551C Hanger Bracket Fijador de Suspensión...
