HTHBHVR*A HTHBHVRBL*A HTHBHVR8*1A HTHBHVR8BL*1A
Installation/Care/Use Manual
Hydroboost Bottle Filling Station and Cooler
THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC. TO WATER
LINES IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY OCCUR AWAY
FROM THE BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTO A FOUNTAIN, CREAT-
ING AN ELECTROLYSIS WHICH CAUSES A METALLIC TASTE OR AN INCREASE IN THE METAL CONTENT
OF THE WATER. THIS CONDITION IS AVOIDABLE BY USING THE PROPER MATERIALS AS INDICATED. ANY
DRAIN FITTINGS PROVIDED BY THE INSTALLER SHOULD BE MADE OF PLASTIC TO ELECTRICALLY ISO-
LATE THE FOUNTAIN FROM THE BUILDING PLUMBING SYSTEM. WE SUGGEST THAT THE BOTTLE FILLING
STATION AND WATER COOLER BE PROTECTED BY A GROUND FAULT CIRCUIT INTERRUPTER (GFCI).
INSTALLER
HTHBHVR8 Bottle Fillers are among the easiest to install on the market today. To
insure you install these models easily and correctly, PLEASE READ THESE SIM-
PLE INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK YOUR
INSTALLATION FOR COMPLIANCE WITH PLUMBING, ELECTRICAL, AND
OTHER APPLICABLE CODES. After installation, leave these instructions with the
Fountain for future reference.
HTHBHVR8 Factory Prep
IMPORTANT! INSTALLER PLEASE NOTE.
IMPORTANT
THIS IS AN INDOOR APPLICATION ONLY.
ALL SERVICE TO BE PERFORMED BY AN
AUTHORIZED SERVICE PERSON.
TOOLS REQUIRED
BUT NOT PROVIDED:
SAFETY GLASSES
GLOVES
ELECTRIC DRILL
3/4" WRENCH OR CRECENT WRENCH
UTILITY KNIFE
TAPE MEASURE
PENCIL
CENTER PUNCH
1/2" SOCKET & RATCHET WRENCH
5/32" ALLEN WRENCH
Page 1
98986C (Rev. A - 5/12)
Advertisement
Table of Contents
Related Manuals for Halsey Taylor HydroBoost HTHBHVR A Series
Summary of Contents for Halsey Taylor HydroBoost HTHBHVR A Series
- Page 1 HTHBHVR*A HTHBHVRBL*A HTHBHVR8*1A HTHBHVR8BL*1A Installation/Care/Use Manual HTHBHVR8 Factory Prep Hydroboost Bottle Filling Station and Cooler IMPORTANT THIS IS AN INDOOR APPLICATION ONLY. ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON. TOOLS REQUIRED BUT NOT PROVIDED: SAFETY GLASSES GLOVES ELECTRIC DRILL 3/4”...
- Page 2 HTHBHVR*A HTHBHVRBL*A HTHBHVR8*1A HTHBHVR8BL*1A Single Rough-In Fig. 1 98986C (Rev. A - 5/12) Page 2...
- Page 3 HTHBHVR*A HTHBHVRBL*A HTHBHVR8*1A HTHBHVR8BL*1A Two -Level Rough-In Fig. 2 Page 3 98986C (Rev. A - 5/12)
- Page 4 HTHBHVR*A HTHBHVRBL*A HTHBHVR8*1A HTHBHVR8BL*1A MOUNTING SCREWS TOP COVER MOUNTING BRACKET FOR FASTENING UNIT BOTTLE FILLER TO WALL MOUNTING SCREW DO NOT REMOVE MOUNTING SCREW DO NOT REMOVE NOTE: TRIM PLATES MUST BE INSTALLED ON THE INSIDE OF THE BOTTLE FILLER SIDE PANEL SLOTS WATER COOLER Fig.
- Page 5 HTHBHVR*A HTHBHVRBL*A HTHBHVR8*1A HTHBHVR8BL*1A REMOVAL OF BOTTLE FILLER FOR SERVICING 1) Turn off the water supply to the Water Cooler(s). Unplug and/or turn off Circuit Braker to Cooler(s) and Bottle Filler. NOTE: the Lower Front Panel of the cooler(s) may need to be removed. To prevent scratching the basin place a towel or soft cloth over the entire basin when working above it. 2) For Single Model Installations: Loosen but DO NOT remove the two (2) Pinned Torx Head Screws from the sides of the Bottle Filler.
- Page 6 HTHBHVR*A HTHBHVRBL*A HTHBHVR8*1A HTHBHVR8BL*1A BF9 PROGRAM SETTING THE CONTROL BOARD VERIFY CONTROL BOARD SOFTWARE SETTING UNIT TYPE 1) To verify the software program of the control board the 1) Depress the program button for approximately 2 seconds unit will need to be shut down and restarted. The chiller until the display changes then release.
- Page 7 HTHBHVR*A HTHBHVRBL*A HTHBHVR8*1A HTHBHVR8BL*1A WATERSENTRY PLUS FILTER PARTS LIST ® LISTA DE PIEZAS DEL FIL- LISTE DES PIÈCES DU FIL- (See Fig. 7) TRO (Vea Fig. 7) TRE (Voir Fig. 7) ITEM NO. PART NO. DESCRIPTION DESCRIPCIÓN DESCRIPTION Filter Head Assy. Ensamblado de la Cabeza del Filtro Ens.
