Danfoss PVG 100 Installation Manual page 6

Installation and technical data for PVPP
(Solenoid operated pilot drain)
Max. operation pressure
Max. coil surface temperature
Rated voltage
Current consumtion
Power consumtion
Max. permissible deviation from rated supply voltage
When installing the wire remember to
connect the built-in diode to the plug
pins.
6
(coil nut)
Position
1
2
22°C (71,6°F) coil temperature
110°C (230°F) coil temperature
22°C (71,6°F) coil temperature
110°C (230°F) coil temperature
11038042 • Rev BC • Feb 2015
2
1
(cartridge valve)
Across flats Max. tightening torque
24 mm
[0.94 in]
20 mm
[0.79 in]
45 Nm
[400 lbf·in]
5 Nm
[44 lbf·in]
350 bar [5076 bar]
155°C [311°F]
12 V –– __ 24 V –– __
1.55 A 0.78 A
1.00 A 0.50 A
19 W 19 W
12 W 12 W
±10%
P106 004E
