Specifications - Extech Instruments SDL400 User Manual

Specifications

General Specifications
Display
Status indicators
Sensor types
Temperature compensation
Measurement Units
Zero Adjust
Datalogger Sampling Rate
Memory Card
Data Hold
Memory Recall
Display update rate
Data Output
Operating Temperature
Operating Humidity
Auto Power OFF
Power Supply
Power Consumption
Weight
Dimensions
www.ponpe.com
Backlit LCD; LCD size: 52 x 38mm (2 x 1.5")
Over-range (----) and low battery
Light: Supplied color corrected, domed light intensity sensor (meets
C.I.E.); Temperature: Thermocouple (J or K) temperature probe
Automatic compensation for thermocouple temperature
measurements
Temperature: °C, °F; Light: LUX, Foot candles
Light function only. Front panel push-button.
AUTO LOGGING: 1, 2, 5, 10, 30, 60, 120, 300, 600, 1800,
3600 seconds. Note that a one (1) second sampling rate
can cause some data loss on slower computers
MANUAL LOGGING: Set the sampling rate to '0'
SD memory card: 1GB to 16GB size
Freeze the displayed reading
Record and Recall the Maximum and Minimum readings
Approx. 1 second.
RS-232 / USB PC computer interface
0 to 50°C (32 to 122°F)
85% R.H. max.
After 10 minutes of inactivity (can be disabled)
Six (6) 1.5 VDC batteries (optional 9V AC adaptor)
Normal operation (backlight & datalogger OFF): approx. 6.5mAdc
With backlight OFF and datalogging ON: approx. 30mAdc
With backlight ON add approx. 16mAdc
346g (0.76 lbs.) meter only
Main instrument: 182 x 73 x 47.5mm (7.1 x 2.9 x 1.9")
11 SDL400-en-GB_V1.6 12/14
