- Page 1 12843 Foothill Blvd. Suite C Sylmar, California 91342 V: 818.898.3380 F: 818.898.3360 sales@dnfcontrols.com Model No.TBC-2-DVC Time Base Corrector Remote Controller For Panasonic DVC VTRs User Manual TBC-2 DVC...
-
Page 2: Table Of Contents
Table of Contents REVISION HISTORY DESCRIPTION INSTALLATION ADJUSTMENTS H PHASE AND SUBCARRIER ADJUSTMENTS S/C COARSE SPECIFICATIONS ADJUSTMENTS DNF CONTROLS LIMITED WARRANTY Manual Version …………….………………………. 1.2 010804 Document No. ………………… TBC-2-DVC_User_Manual.doc TBC-2 DVC... -
Page 3: Revision History
REVISION HISTORY 010804 Rev. 1.2 Company header information revised. Added DNF Controls Limited Warranty. Reformatted. DESCRIPTION The TBC 2-DVC is designed to control the built-in time base correctors in the Panasonic DVC Pro VTRs. The TBC 2 controls the basic TBC adjustments:... -
Page 4: Installation
INSTALLATION Connect one end of a D-sub15 cable to the TBC 2. Connect the other end of the cable to the D-sub 15 on the VTR to be controlled. Identified as “Encoder Remote” or “Video Control.” Because the TBC Remote connector has power on its pins, cabling should be done only with the VTR power switch turned off. -
Page 5: Adjustments
ADJUSTMENTS Each control is clearly labeled for its function. Each control may be adjusted over a wide range. Each control may be switched “in” or “out” by using the toggle switch located below the control. The “out” position sets that function to unity gain (as set within the VTR). The “in” position enables the associated control. -
Page 6: Specifications
SPECIFICATIONS 2 TBC Controllers in 1 RU housing Physical: L x W x H: 19” x 2-1/2” x 1-3/4” Weight: 2 lbs. ADJUSTMENTS FRONT PANEL CONTROL VIA KNOB (All with individual bypass switch on front panel) Video Gain Range: +/- 3dB (+/- 20 IRE) Setup Range: +/- 15 IRE C-Gain: Hue Range: +/- 30 Degrees... -
Page 7: Dnf Controls Limited Warranty
DNF CONTROLS LIMITED WARRANTY DNF Controls warrants its product to be free from defects in material and workmanship for a period of one (1) year from the date of sale to the original purchaser from DNF Controls. In order to enforce the rights under this warranty, the customer must first contact DNF’s Customer Support Department to afford the opportunity of identifying and fixing the problem without sending the unit in for repair.
