YEARS: 2016
MAKE:
WARNING: NEVER EXCEED YOUR VEHICLE MANUFACTURER'S RECOMMENDED TOWING CAPACITY
For more information log onto www.curtmfg.com & for helpful towing tips log onto www.hitchinfo.com
WEIGHT CARRYING:
PRO INSTALL TIME:
NOVICE INSTALL TIME:
IF YOU ARE HESITANT TO UNDERTAKE
THIS TASK ON YOUR OWN, CONTACT AN AUTHORIZED
CURT INSTALLER FOR ADDITIONAL ASSISTANCE.
INSTALLATION REQUIRES:
7mm
13mm
3/4"
PANEL REMOVAL
SOCKET
TOOL
9"
TORQUE
SOCKET
WRENCH
EXTENSION
PHILLIPS HEAD
ROTARY TOOL
SCREW DRIVER
PERIODICALLY CHECK THIS RECEIVER HITCH TO ENSURE ALL FASTENERS ARE TIGHT AND ALL STRUCTURAL COMPONENTS ARE SOUND
CURT Manufacturing LLC. warrants this product to be free of defects in material and/or workmanship at the time of retail purchase by the original purchaser. If the product is found to be defective,
CURT Manufacturing LLC. may repair or replace the product at their option, when the product is returned, prepaid, with proof of purchase. Alteration to, misuse of, or improper installation of this product
SCAN FOR
voids the warranty. CURT Manufacturing LLC.'s liability is limited to repair or replacement of products found to be defective, and specifically excludes liability for incidental or consequential loss or damage.
MORE INFO
For more information log onto www.curtmfg.com, & for helpful towing tips log onto www.hitchinfo.com
This product complies with safety specifications and requirements for connecting devices and towing systems of the state of New York, V.E.S.C.Regulation V-5 and SAE J684.
11433
INSTALLATION INSTRUCTIONS
CHEVROLET
TRAILER WEIGHT:
LBS.
2000
TONGUE WEIGHT:
200
LBS.
40
MIN.
INSTALLATION TIPS:
80 MIN.
1. BEFORE YOU BEGIN INSTALLATION, READ ALL
INSTRUCTIONS THOROUGHLY.
2. TO EASE INSTALLATION, 2 PEOPLE MAY BE
REQUIRED.
3. USING PROPER TOOLS WILL GREATLY IMPROVE
THE QUALITY OF THE INSTALL AND REDUCE THE
TIME REQUIRED.
4. NEED HELP OR HAVE SOME QUESTIONS?
CALL TECHNICAL SUPPORT AT 800.798.0813
LEVEL OF DIFFICULTY:
EASY
RATCHET
MASKING
TAPE
SAFETY
1.125"
GLASSES
MODEL: SPARK
WARNING:
WE RECOMMEND THE USE OF 18050 STABILIZING STRAPS FOR ALL NON-TRAILER
(WHEEL-LESS) LOADS. PLEASE SEE THE CURT CATALOG OR VISIT US ONLINE AT
WWW.CURTMFG.COM FOR FURTHER INFORMATION.
MODERATE
MODERATE
CHALLENGING
FISHWIRE HARDWARE
REVERSE FISHWIRE HARDWARE
ENLARGE ACCESS HOLE
TrimMING REQUIRED
Safety glasses should be
worn at all times while
installing this product .
STYLE:
VEHICLE PHOTO:
REPRESENTATIVE PHOTO
HITCH ILLUSTRATION:
MAKE SURE YOUR HITCH MATCHES
HATCHBACK
3/25/2016
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for curt 11433
Summary of Contents for curt 11433
- Page 1 PERIODICALLY CHECK THIS RECEIVER HITCH TO ENSURE ALL FASTENERS ARE TIGHT AND ALL STRUCTURAL COMPONENTS ARE SOUND CURT Manufacturing LLC. warrants this product to be free of defects in material and/or workmanship at the time of retail purchase by the original purchaser. If the product is found to be defective, CURT Manufacturing LLC.
- Page 2 INSTALLATION WALKTHROUGH: Parts List 1. Remove two (2) push button fasteners and two (2) hex bolts ITEM PART NUMBER DESCRIPTION from vehicle fascia using a 7mm socket. Save and set aside CM-SP12 .250 x 1.00 x 2.00" SQUARE HOLE SPACER for reinstall later.
- Page 3 INSTALLATION WALKTHROUGH: 3. Enlarge rear-most hole on driver and passneger side to dimensions 7. Pull fascia down and raise hitch into position by sliding passenger side shown on PAGE 1 to allow 1/2" carriage bolts, CM-SP6, and plate under plastic tab as shown below. CM-SP12 to pass into frame rails 8.
- Page 5 CURT Manufacturing LLC., warrants this product to be free of defects in material and/or workmanship at the time of retail purchase by the original purchaser. Scan If the product is found to be defective, CURT Manufacturing LLC., may repair or replace the product, at their option, when the product is returned, prepaid, for more with proof of purchase.
- Page 6 ARE TIGHT AND THAT ALL STRUCTURAL COMPONENTS ARE SOUND. CURT Manufacturing LLC., warrants this product to be free of defects in material and/or workmanship at the time of retail purchase by the original purchaser. If the product is found to be defective, CURT Manufacturing LLC., may repair or replace the product, at their option, when the product is returned, prepaid, with proof of purchase.
