YEARS: 2014
MAKE:
WARNING: NEVER EXCEED YOUR VEHICLE MANUFACTURER'S RECOMMENDED TOWING CAPACITY
WEIGHT CARRYING:
PRO INSTALL TIME:
NOVICE INSTALL TIME:
IF YOU ARE HESITANT TO UNDERTAKE
THIS TASK ON YOUR OWN, CONTACT AN AUTHORIZED
CURT INSTALLER FOR ADDITIONAL ASSISTANCE.
INSTALLATION REQUIRES:
6 in.
SOCKET
EXTENSION
RATCHET
SCREW
TORQUE
DRIVER
WRENCH
SAFETY
GLASSES
DIE GRINDER
PANEL REMOVAL
RECIPROCATING
TOOL
SAW
PERIODICALLY CHECK THIS RECEIVER HITCH TO ENSURE ALL FASTENERS ARE TIGHT AND ALL STRUCTURAL COMPONENTS ARE SOUND
CURT Manufacturing LLC. warrants this product to be free of defects in material and/or workmanship at the time of retail purchase by the original purchaser. If the product is found to be defective, Curt Manufacturing LLC. may repair or replace
the product at their option, when the product is returned, prepaid, with proof of purchase. Alteration to, misuse of, or improper installation of this product voids the warranty. Curt Manufacturing LLC.'s liability is limited to repair or replacement
of products found to be defective, and specifically excludes liability for incidental or consequential loss or damage.
11376
INSTALLATION INSTRUCTIONS
MERCEDES-BENZ
TRAILER WEIGHT:
1,000
TONGUE WEIGHT:
100
120
MIN.
INSTALLATION TIPS:
240
MIN.
1. BEFORE YOU BEGIN INSTALLATION, READ ALL
INSTRUCTIONS THOROUGHLY.
2. TO EASE INSTALLATION, 2 PEOPLE MAY BE
REQUIRED.
3. USING PROPER TOOLS WILL GREATLY IMPROVE
THE QUALITY OF THE INSTALL AND REDUCE THE
TIME REQUIRED.
3/4 in.
10mm
LEVEL OF DIFFICULTY: CHALLENGING
17mm
EASY
SOCKET
MASKING
TAPE
TAPE
MEASURE
PART REMOVAL
MODEL: SLK250
LBS.
LBS.
MODERATE
CHALLENGING
DRILLING / HOLE ENLARGEMENT
REQUIRED
FISHWIRE HARDWARE
CLEAN EXISTING WELDNUTS
TEMPORARILY REMOVE TRUNK
CONTENTS, INTERIOR PANEL,
BUMPER COVER
TRIM FOAM BUMPER PAD
AND REAR FASCIA
Safety glasses should be
worn at all times while
installing this product .
STYLE:
VEHICLE PHOTO:
REPRESENTATIVE PHOTO
TRAILER HITCH
ILLUSTRATION:
MAKE SURE YOUR HITCH MATCHES
CONVERTIBLE
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for curt 11376
Summary of Contents for curt 11376
- Page 1 CURT Manufacturing LLC. warrants this product to be free of defects in material and/or workmanship at the time of retail purchase by the original purchaser. If the product is found to be defective, Curt Manufacturing LLC. may repair or replace...
- Page 2 Parts List 1. Remove trunk contents including the spare tire cover, ITEM PART NUMBER DESCRIPTION spare tire, and spare tire tool kit. 11376-SP .250" SPACER PLATE HFN 1213, GR8 HEX FLANGE NUT 1/2-13 x 1 3/4, GR8 CARRIAGE BOLT M10 - 1.5 x 40mm HEX BOLT 3/8"...
- Page 3 INSTALLATION WALKTHROUGH: 3. Gently remove rear panel. 5. Using a 10 mm socket, remove two (2) plastic nuts from underbody panel (1 per side). Do not remove middle nut. 6. Using a flat head screwdriver, remove three (3) plastic clips 4.
- Page 4 INSTALLATION WALKTHROUGH: 7. Gently pull corners of rear fascia loose. Using a panel 9. Gently remove rear fascia. removal tool, gently detach clips (5 per side) located below tail lights. 8. Using a 10mm socket, remove center nut from inside of 10.
- Page 5 INSTALLATION WALKTHROUGH: 11. Detach electrical connections (4 connectors and 1 clip) from 13. Remove two (2) plastic plugs from rear body panel. rear fascia. REMOVE PLUGS 12. Using a T50 Torx bit, remove two (2) M10 screws 14. Using a die grinder, enlarge two (2) holes where plastic connecting underbody supports to trunk pan.
- Page 6 INSTALLATION WALKTHROUGH: 15. Reverse fishwire 1/2" carriage bolts and CM-SP19 17. Place CM-11376-SP spacers between forward mounting spacers into the enlarged holes. Fishwires should plate and underbody supports. Loosely install M10 hex remain attached to preven loss of hardware. bolts and 3/8" conical toothed washers into the existing (See Reverse Fishwire Diagram) vehicle weldnuts.
- Page 7 INSTALLATION WALKTHROUGH: 19. Mark with masking tape and trim with reciprocating saw the 21. Reassemble rear fascia with foam bumper pad and foam bumper pad. (See Foam Bumper Pad Trim Diagram) reattach electrical connections. 3 1/4 in. BUMPER PAD CENTER 17 1/2 in.
- Page 8 INSTALLATION WALKTHROUGH: 24. Reattach interior panel in reverse order of removal. 26. Install complete. 25. Reinstall spare tire kit, spare tire and spare tire cover.
- Page 9 ARE TIGHT AND THAT ALL STRUCTURAL COMPONENTS ARE SOUND. Curt Manufacturing LLC., warrants this product to be free of defects in material and/or workmanship at the time of retail purchase by the original purchaser. If the product is found to be defective, Curt Manufacturing LLC., may repair or replace the product, at their option, when the product is returned, prepaid, with proof of purchase.
- Page 10 ARE TIGHT AND THAT ALL STRUCTURAL COMPONENTS ARE SOUND. Curt Manufacturing LLC., warrants this product to be free of defects in material and/or workmanship at the time of retail purchase by the original purchaser. If the product is found to be defective, Curt Manufacturing LLC., may repair or replace the product, at their option, when the product is returned, prepaid, with proof of purchase.
-
Page 11: Installation Steps
ARE TIGHT AND THAT ALL STRUCTURAL COMPONENTS ARE SOUND. Curt Manufacturing LLC., warrants this product to be free of defects in material and/or workmanship at the time of retail purchase by the original purchaser. If the product is found to be defective, Curt Manufacturing LLC., may repair or replace the product, at their option, when the product is returned, prepaid, with proof of purchase.
