Adding A System Field; Adding A Simple Field - BEA SWIFT Adapter User Manual

See Also:
Creating an empty Service/System message format

Adding a System Field

Adding a Group
Adding a System Field
A system field can be either
A simple field. A field that does not have any sub-fields. For e.g. field 'swift-
address' (tag 102). The format of the field is '4!a2!a2!c1!c3!c'.
A complex field. A field that consists of several sub-fields. For e.g. field 'mir' (tag
106) has the following format '(6!n)(4!a2!a2!c1!c)(3!c)(4!n)(6!n)'.
See Also:

Adding a Simple Field

Adding a Complex Field
Fields Separated by OR/AND
Adding a Group
System Field Dictionary
Adding a Simple Field
A simple field is a field that does not have any sub-fields. For e.g. field 'swift-
address' (tag 102). The format of the field is '4!a2!a2!c1!c3!c'. To add the field the
following steps need to be performed.
1. In the SWIFT external format UI, click the
dialog will be displayed.
2. Select the field to be added ('swift-address') in the 'Name' combo box. Or else
you can type the field tag (102) in the 'Tag' combo box. The format details of the
field are displayed.
button. The 'Add System Field'
