Customize Field

Consider the message format MT101.
Status Tag Field Name
Mandatory Sequence A General Information
M 20
O 21R
M 28D Message Index/Total
O 50a
O 50a
O 52a
.......
.......
.......
Note that the field 50a appears twice consequently. When such a data format is
entered in the designer and validated, the designer shows an error that the field is
duplicated. Hence in order to avoid this, the suffix a needs to be changed. Anyhow,
this will not affect the format of the field. To change the suffix:
1. Click the Add New SWIFT Field
to bring the Create Field dialog. Or select the row to change the suffix (if the
field is already added) and click the Modify SWIFT Field button to bring the
Modify Field dialog.
Sender's Reference
Customer Specified
Reference
Instructing Party
Ordering Customer
Account Servicing
Institution
button in the External Format - SWIFT UI
Content/Options No.
16x
16x
5n/5n
C or L
G or H
A or C
1
2
3
4
5
6
