BEA SWIFT Adapter User Manual page 52

Number of lines that range between 1 and maximum number possible is present
in format A along with format B.
Maximum number of lines that is possible is present in format A along with
format B.
In this format pattern, format A can have multiple lines in its data, which are
separated by CRLF. Format A and Format B are also separated by CRLF. In order to
differentiate between the data for format A and data for format B we have followed
the above conversion pattern. In this case, format A is represented as a combination
of the number of possible lines and the maximum length per line. The order of the
formats is important and should always be maintained.
Example
Field
Format
Specification
Format in
Designer
Specification
in Designer
Present in Message Format: MT710
See Also:
Adding a new Generic Field
Adding a Non-Generic Field
Mapping Formats with Specification (Sub-fields)
41a – OPTION D
(4*35x)CRLF14x
(Name & Address)(Code)
(35x)CRLF14x|(2*35x)CRLF14x|(3*35x)CRLF14x|
(4*35x)CRLF14x
(Name & Address)(Code) |(Name & Address)(Code) |
(Name & Address)(Code) |(Name & Address)(Code)
