Warranty

EXTECH INSTRUMENTS CORPORATION warrants this instrument to be free of defects in parts and workmanship for one
year from date of shipment (a six month limited warranty applies on sensors and cables). If it should become necessary to
return the instrument for service during or beyond the warranty period, contact the Customer Service Department at (781)
890-7440 ext. 210 for authorization or visit our website at www.extech.com (click on 'Contact Extech' and go to 'Service
Department' to request an RA number). A Return Authorization (RA) number must be issued before any product is returned
to Extech. The sender is responsible for shipping charges, freight, insurance and proper packaging to prevent damage in
transit. This warranty does not apply to defects resulting from action of the user such as misuse, improper wiring, operation
outside of specification, improper maintenance or repair, or unauthorized modification. Extech specifically disclaims any
implied warranties or merchantability or fitness for a specific purpose and will not be liable for any direct, indirect, incidental
or consequential damages. Extech's total liability is limited to repair or replacement of the product. The warranty set forth
above is inclusive and no other warranty, whether written or oral, is expressed or implied.

Specifications

General Specifications
Circuit
Display
Connection type
Measurement ranges
Test voltage
Comparator
Zero adjust
Over-range indication
Operating Temperature
Operating Humidity
Power Supply
Weight
Dimensions
Range Specifications
Range Resolution
20 mΩ 0.01mΩ
200 mΩ 0.1mΩ
2 Ω
.001Ω
20 Ω
.01Ω
200 Ω 0.1 Ω
2K Ω
.001kΩ
20K Ω
.01kΩ
Note: Specifications based on RF Field Strength <3V/m and frequency <30MHz
International Symbols
Custom one-chip LSI microprocessor circuit
0.7" (18 mm) 2000 Count LED Display
4-Terminal Kelvin
Seven ranges (see listing below)
5V DC
Built-in HI/LO/GO testing with audible beeper
Automatic (no adjustment necessary)
Display reads "1____" when the reading is out of range
32°F to 122°F (0°C to 50°C)
Max. 80% RH
110V (380560) or 220V (380562) ±15%, 50/60Hz
4.85 lbs (2.2kg)
11 x 8 x 3.5" (280 x 210 x 90mm)
Test Current Accuracy (%rdg)
1A ± (0.2% + 6 digits)
1A
0.1A
10mA
± (0.2% + 4 digits)
1mA
0.1mA
10uA
2
Test Voltage
2.7V DC
3.3V DC
3.5V DC
4.1V DC
4.5V DC
380560, Version 1.6, 04/03
