2. Power source input
■ When wiring power source from outdoor unit
■ When using external power source
Notes
This device can accept only DC Power input.
Do not input 220VAC. Otherwise It will cause a serious damage.
Using external power source is recommended.
Setting and using method
DC12V or DC15V
GND
Outdoor Unit
PCB
DC12V
GND
Power Source
Installation manual 9
